2.3.6 The function of the Menu

3645A power supply provides a Menu operation for some special functions. The operation
and function are as following.
Procedure
Step 1
Step 2
Step 3
Step 4
The menu operation includes MAX OUT VOLTAGE, KEY SOUND SET, COMMUNICA-
TION SET, ADDRESS SET, KEY LOCK, MAX OUT POWER, and Save set function. We will
descript the details as following.

2.3.6.1 Set up the maximum voltage output value (0~36V)

When you select the MAX OUT VOLTAGE function, the LCD will display as:

2.3.6.2 Set up the key sound

When you select the KEY SOUND SET function, the LCD will display as:
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
The operation Methods
Press "Menu" button
Enter the password ( Or jump to step 4 if the keyboard
is unlocked)
Press "Enter" button ( it will return to step 2 if your
password is wrong for reentering)
The LCD display the menu functions one by one, user
can use the UP and DOWN button to change the
selecting each function, Press "Enter" button to execute COMMUNICATION SET
the selected function
It will exit the Menu operation at any procedure by press ESC button
MAX VOLT = 24 V
NEW=
KEY SOUND ON
KEY SOUND OFF
3645A-TYPE USER'S MANUAL
You can set the voltage value by using the UP and
DOWN key or rotating the ROTARY button. Then con-
firm the value by pressing "Enter" button.
Users can select KEY SOUND ON or KEY SOUND
OFF by using UP and DOWN key button. KEY SOUND
ON represent the sound of keys will be on , and KEY
SOUND OFF represent the sound of keys will be off.
LCD display
0.000V 0.00A
0.00W OFF
ENTER PASSWORD
ENTER PASSWORD
1234
MAX OUT VOLTAGE
KEY SOUND SET
ADDRESS SET
KEY LOCK
MAX OUT POWER
SAVE SET
EXIT
12
