Programmable
Power supply
3645A
user's manual
CONTENTS
Caution.........................................................2
Safety notes..................................................2
Chapter 1 General Introduction ...................3
1.1 General Introduction...............................3
1.2 Specification...........................................3
1.3 Features ................................................4
1.4 Dimension and Structure........................4
1.4.1 Dimension............................................4
1.4.2 Structure..............................................5
1.4.2.1 Front view ........................................5
1.4.2.2 Back view..........................................6
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
3645A-TYPE USER'S MANUAL
Chapter 2 Operation.....................................7
2.1 General operation ..................................7
2.2 Function introduction...............................7
2.2.1. Main functions.....................................7
2.2.2 Sub-functions.......................................7
2.3 The operation of the function...................7
2.3.1 V-set....................................................8
2.3.2 I-set......................................................9
2.3.3 Switch ON/OFF power output...............9
2.3.4 Store data function...............................10
2.3.5 Recall data function............................11
2.3.6 The function of the Menu...................12
output value (0~36V).......................12
2.3.6.2 Set up the key sound......................13
2.3.6.3 Set up the communication...............13
address (0~254)..............................13
2.3.6.5 Set up locking key board..................13
2.3.6.6 Set up constant power output..........14
2.3.6.7 Set up save option...........................14
2.3.6.8 Exit function.....................................14
Chapter 3 System Installation...................15
3. 1 System Installation..............................15
3.2.System Start..........................................17
The Function Introduction.......18
4.1 Users' Login.........................................18
(Power Supply) Address Set.................19
4.4 Run the Communication........................20
4.5 Stop the Communication.......................20
4.6 Select POWER.....................................21
Control Instructions...............................21
4.8 Set the Voltage Range..........................21
4.9 Set the Max Current..............................21
4.10 Users' Manage....................................23
4.11 Query the Report................................24
Indicating Components.......................25
4.13 The State Bar.....................................26
4.14 Help....................................................25
4.15 Logout User........................................26
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Array electronic 3645A
Summary of Contents for Array electronic 3645A
-
Page 1: Table Of Contents
1.3 Features ..........4 4.12 Explanation of the Interface 1.4 Dimension and Structure......4 Indicating Components.......25 1.4.1 Dimension..........4 4.13 The State Bar........26 1.4.2 Structure..........5 4.14 Help............25 1.4.2.1 Front view ........5 4.15 Logout User........26 1.4.2.2 Back view..........6 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 2: Caution
Because of the danger of introduction additional hazards, do not install substitute parts or perform any unauthorized modification to the instrument. Return the instru- ment to a qualified dealer for service and repair to ensure that safety features are maintained. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 3: Chapter 1 General Introduction
Chapter 1 General Introduction General Introduction 3645A-Type programmable DC power supply is designed and manufactured by ARRAY Electronic Co., ltd. This instrument is a kind of mini-size DC programmable power supply with nice appearance. Also it is equipped with back-light LCD display, number keypad and rotary code switch which let it much easier to use. -
Page 4: Features
9. Can be set by number key or rotary code switch. 10. Power shut-down memory function 11. Monitored by PC software. 12. Mini-size and removable light weight. 13. Can be used as series connect and parallel connect. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 5: Structure
And in special mode, it will change into the functions of the orange color words. the current mode. mV/ mA :Represent mV at the voltage mode, and represent mA at the current mode 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 6: Back View
Power supply plug fan wrap Fuse Change over Switch Fig 6 Back view The fuse can be changed easily by using a small screw driver. Please use a fuse within the range of 2~2.5A. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 7: Chapter 2 Operation
We know that there are 5 main functions and 6 sub-functions of this power supply, the following will descript how to operate all of the functions. Before any operation, please connect the power, and switch the power on, then the power indicator will be lighted. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 8: V-Set
Set up a constant DC voltage output is the first main function of programmable DC power supply, 3645A power supply provides two methods to set up the constant DC voltage output by using the number keyboard and the rotary button. Please see the following operation procedure. -
Page 9: I-Set
2.3.2 I-set (set up a constant current or a maximum current from 0 to 3A) 3645A power supply can be set u p for a constant current or a maximum current from 0 to 3A, and there are two special application for users when he set up the I-set, please see the following example. -
Page 10: Store Data Function
Maximum output power=25W, Baud rate=9600, communication address=05, after done the setup , users can store all the above setup as a set of data, such as the 01 or 02 etc set date. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 11: Recall Data Function
Press “Recall” button to confirm , if the number is out of RECALL * the range from 1 to 10, it will retune to Step 2 for reenter It will exit the Recall operation at any procedure by press ESC button 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 12: The Function Of The Menu
3645A-TYPE USER’S MANUAL 2.3.6 The function of the Menu 3645A power supply provides a Menu operation for some special functions. The operation and function are as following. Procedure The operation Methods LCD display Step 1 Press “Menu” button 0.000V 0.00A 0.00W OFF... -
Page 13: Set Up The Communication
ROTARY ENTER PASSWORD button to keys to change the number or ASCII number which will be your password, and confirm the password by pressing “Enter” button. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 14: Set Up Constant Power Output
VOLTAGE means to save the last set up voltage, to select DON T SAVE VOLT means not to save the last set up voltage value. 2.3.6.8 EXIT function When the EXIT function is selected, you will exit the Menu operation. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 15: Chapter 3 System Installation
Fig. 3-3 The Installation Interface 3 3.4 In Fig. 3-4, click “BROWSE” to select installation directory path. The default directory path is “C: \Program Files\Array\PowerMS” 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... - Page 16 3.1.7 Click “NEXT” and the installation system will enter the files’ copying state. Please wait patiently for the end of the files’ copying. Then the PowerMS system installation is finishing. Fig. 3-7 The Installation Interface 7 The Files’ Copying 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3...
-
Page 17: System Start
Click the right key of the mouse on the icon, the menu as shown in Fig. 3-11 will be displayed. Fig. 3-11 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 18: Chapter 4 The Function Introduction
Fig.4-1 The User Login Interface 4.2 The Definition of the Power Supply Select the function item and then the interface as shown in Fig. 4-2 will be displayed. Fig. 4-2 The Power Definition Interface 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 19: The Com Port And Lower Machine (Power Supply) Address Set
Fig. 4-5. And the “OK” button and the page key “ADDRESS” are out of work. And vice versa. (And users must be in the identity of the “Manager” otherwise the “ADDRESS” cannot be used. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 20: Run The Communication
Fig. 4-9 will be displayed. Fig. 4-8 Normal Communication Fig.4-9 Failure Communication 4.5 Stop the Communication Select the button and the system will stop the communication. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 21: Select Power
There are two methods to set the voltage range: one is by using the rotary button (1~36) and the other is by using the keyboard (0.004~36.000). If you want to set accurately, please use the keyboard. In general state, you can use the rotary button. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... - Page 22 Explanation: The user “Lowest” is retained by the system and cannot be modified. 3.) Query User(s) Select the page key “USER(S)”, the dialogue frame as shown in Fig. 4-18 will be displayed. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3...
-
Page 23: Users' Manage
Fig. 4-20 Clearing Data Prompting Fig. 4-21 User Operating Information Click the right key of the mouse and query according to the users’ name or date. And the following dialogue will be displayed. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 24: Query The Report
6.) Delete the History Record: Select “DELETE” and the diagram as shown in Fig. 4-24 will be displayed. If you confirm to delete, select “YES” and it will be OK. Fig. 4-24 Delete the History Data 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 25: Explanation Of The Interface Indicating Components
V: presents the current voltage set state (Unit: V). Keyboard Explanation Max 36: presents that the max set voltage value is 36. 0: the current set value 4.14 Help Power: p3: presents the current selected POWER. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3... -
Page 26: Logout User
4.Power supply control type: Blue presents CONROL SELF. Red presents PC CONTROL. 4.17 Exit the System Select the icon . To do this, you must login first, otherwise the system cannot be closed. 3645A Programmable Power Supply ARRAY ELECTRONIC CO.,LTD 2002.3...
