Installation Manual
EF5000 - US
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
-
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other gas appliance.
WHAT TO DO IF YOU SMELL GAS:
-
o Do not try to light any appliance.
o Do not touch any electrical switch; do not use any phone in your
building.
o Immediately call your gas supplier from a neighbour's phone. Follow
the gas suppliers instructions.
o If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service
-
agency or gas supplier.
Instructions must be left with the consumer and the consumer to retain
-
them for future reference
WARNING: Improper installation, adjustment, alteration, service or maintenance
can cause injury or property damage. Read the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment.
WARNING: For Outdoor Use Only.
630162_2 EF5000 Installation Guide R‐emotion ‐ US
Advertisement
Table of Contents
Related Manuals for Escea EF5000
Summary of Contents for Escea EF5000
- Page 1 Installation Manual EF5000 - US WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other gas appliance.
- Page 2 Under no circumstances should you touch the coals or metalwork during operation. Contact: For further information or advice please contact: Ph. USA: 1 866 615 3096 Email: techsupport@escea.net Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220, email: info@escea.net 630162_2 EF5000 Installation Guide R‐emotion ‐ US ...
-
Page 3: Table Of Contents
Connecting the power supply and touch panel 11.0 Testing of touch panel and spark ignition 12.0 Checking operating pressure 13.0 Assembly of stone cartridge 14.0 Fitting the fascia 15.0 Placement of ceramic pebbles 16.0 Operating Instructions 17.0 Maintenance and cleaning 18.0 Replacement Parts 19.0 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... -
Page 4: Product Description
Product Description: The escea EF5000 flame effect gas fire is designed for outdoor use only. This appliance requires no flue and must be permanently installed into a cavity. It may be installed into a timber cavity. The fire is controlled by the user, from a touch panel that is situated on the lower right hand side of the stainless steel fascia, or if the ‘wall mount’... -
Page 5: Power Supply
Amp capacity. Connect the transformer to the fire by putting the Positive wire into the Red terminal of the control tray, then connect the Negative wire to the Black terminal. THIS MUST ONLY BE DONE BY AN AUTHOURIZED ELECTRICIAN 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... -
Page 6: Creating The Cavity
6’. Warning: Under no circumstances should any object such as people, pets, furniture, etc. be closer than 3 feet in front of the escea EF5000. Note: The 1 ½” clearance is also required on the... -
Page 7: Wall Cladding Around The Fire
Typically an outdoor space is not enclosed but, any enclosure in which the appliance is used shall comply with one of the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover. 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... - Page 8 At least 30% of the remaining wall area is open and unrestricted Rectangular areas have been used in the above diagrams, the same principles apply to any other shaped area. In the case of balconies, at least 20% of the total wall area shall be and remain open and unrestricted. 630162_2 EF5000 Installation Guide R‐emotion ‐ US ...
-
Page 9: Corner Installations
Allowances need to be made for the internal cladding of the cavity. Dimensions of the cavity in this ” diagram represent the internal 13” size only. 65 ¾” Minimum clearance distance between adjacent wall and fascia to be no less than 11”. 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... -
Page 10: Laying Gas Pipe
It is required by law that an approved shut off valve (not supplied) be installed in the line between the EF5000 Gas Fire and the gas supply. All hoses and gas pipes must be located out of pathways where people may trip over it and must not be in areas where the hose may be subject to accidental damage. -
Page 11: Fixing The Fire Into The Cavity
The hose and pipe assembly should have been tested prior to this as per section 8.2 10.1 The regulator that is supplied in the fire MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with an Escea EF5000, will void the limited appliance warranty. 10.2 The EF5000 must be isolated from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½... -
Page 12: Connecting The Power Supply And Touch Panel
This can be done with the gas supply either turned on or off. With the power supply and touch panel connected, Lean the fascia Right end up beside the fire and run through the steps for igniting the pilot (refer to section 17.0 for instructions). 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... -
Page 13: Checking Operating Pressure
The manifold pressure has been factory set. Please check that the manifold pressure is as listed below by checking at the outlet test point. 13.3 Replace operating test point screw and leak test the test point. EF5000 Pressure table EF5000 Pressure table Propane Natural... -
Page 14: Assembly Of Stone Cartridge
(River Stones) are also supplied, use these to fill the stone cartridge. 14.1 With the glass in position, fix the stone cartridge to the fire by using the two supplied screws in the location shown below. Do this before the fascia is fitted. 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... -
Page 15: Fitting The Fascia
Before fitting the fascia, the hooks must be attached using the screws provided. Ensure the two wires connecting the fascia to the fire are securely connected, as per section 11.0. The EF5000 Stainless Steel fascia is attached to the combustion box by four ‘hooks’ on the corners of the fascia. - Page 16 16.0 Placement of ceramic stones: EF5000 fuel beds should be evenly spread out with a maximum one layer of media. Do not heap or mound the fuel bed media, but attempt to get an even spread across the top of the burners.
-
Page 17: Operating Instructions
17.0 Operating Instructions: The EF5000 is operated by the touch control panel located on the Right hand side outer edge of the fascia. The basic operations possible from the touch control are ON/OFF and manual adjustment of the flame height. -
Page 18: Adjusting The Flame Height
Once the pilot flame has been running for at least 6 seconds press the FLAME UP (1) button to start the gas to the two main burners 17.6 The EF5000 has 4 flame positions: PILOT flame only, LOW burner flame, MEDIUM burner flame and HIGH burner flame. 17.7 Adjusting the flame height... -
Page 19: Maintenance And Cleaning
18.2 Periodical visual checks of the pilot and burner flames should be carried out to ensure consistent flame and clean burning, then turn off the battery isolating switch. 19.0 Electrical Schematic Part No. 620261_1 630162_2 EF5000 Installation Guide R‐emotion ‐ US ... - Page 20 630162_2 EF5000 Installation Guide R‐emotion ‐ US ...
- Page 21 0.433” 0.236” Rear Burner Aeration Hole 0.433” 0.236” 56000 54000 For certification inquires, please contact certinfo@csa-international.org or contact our Client Services Centre at 1.866.797.4272 or (416) 747-2661 CSA. Cleveland, Ohio 8501 East Pleasant Valley Road Cleveland, Ohio, USA, 44131-5575 630162_2 EF5000 Installation Guide R‐emotion ‐ US ...
-
Page 22: Replacement Parts
ESCEA operating and maintenance instructions, then for the first period of twelve (12) months from the date of purchase ESCEA will pay to the dealer who sold the appliance, a pre-determined sum to repair or replace any part of the Product that is deemed by ESCEA to be faulty.
