Installation Manual
EF5000 - US
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
DANGER - WHAT TO DO IF YOU SMELL GAS:
o Do not try to light any appliance.
o Do not touch any electrical switch; do not use any phone in your
building.
o Immediately call your gas supplier from a neighbour's phone. Follow
the gas suppliers instructions.
o If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service
agency or gas supplier.
-
Instructions must be left with the consumer and the consumer to retain
them for future reference
WARNING: Improper installation, adjustment, alteration, service or
can cause injury or property damage. Read the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment.
WARNING: For Outdoor Use Only.
DANGER
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
pour les documents français vont à www.escea.com/technical
630298_3 EF5000 Installation Guide - US
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which
has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as
a camper, tent, car or home.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other
appliance.
An LP-cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance
maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EF5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Escea EF5000

  • Page 1 An LP-cylinder not connected for use shall not be stored in the vicinity your gas supplier or fire department. of this or any other appliance pour les documents français vont à www.escea.com/technical 630298_3 EF5000 Installation Guide - US...
  • Page 2 For further information or advice please contact the following Escea distributor: Firebrands Ph. USA: (866) 343-3130 Email: sales@firebrands.com Website: www.firebrands.biz Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220, email: info@escea.com 630298_3 EF5000 Installation Guide - US...
  • Page 3 Consumption 2.3 W @ 0.021A 110V Battery Pack (4 x AA Cells) or optional 6.0V DC Electric transformer Connections ½ “ NPT female lower left of fireplace Data badge location Lower left of fireplace 630298_3 EF5000 Installation Guide - US...
  • Page 4: Table Of Contents

    Testing of touch panel and spark ignition 12.0 Checking operating pressure 13.0 Assembly of stone cartridge 14.0 Fitting the fascia 15.0 Placement of ceramic pebbles 16.0 Operating Instructions 17.0 Maintenance and cleaning 18.0 Replacement Parts 19.0 630298_3 EF5000 Installation Guide - US...
  • Page 5: Product Description

    Product Description: The Escea EF5000 flame effect gas fire is designed for outdoor use only. This appliance requires no flue and must be permanently installed into a cavity. It may be installed into a timber cavity. The fire is controlled by the user, from a touch panel that is situated on the lower right hand side of the stainless steel fascia, or if the ‘wall mount’...
  • Page 6: Power Supply

    If you wish to connect your outdoor fire to mains electricity instead of using 4x AA sized batteries, you may do so using the transformer available for purchase through your Escea retailer capable of a 6V DC output (Make sure to provide sufficient protection to the mains connection).
  • Page 7: Creating The Cavity

    3 feet in WALL front of the Escea EF5000. 3’ Note: The 1 ½” clearance is also required on the sides of the fascia to allow access to 1 ” Minimum the control panel. SIDE VIEW 630298_3 EF5000 Installation Guide - US...
  • Page 8: Wall Cladding Around The Fire

    Typically an outdoor space is not enclosed but, any enclosure in which the appliance is used shall comply with one of the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover. 630298_3 EF5000 Installation Guide - US...
  • Page 9 Rectangular areas have been used in the above diagrams, the same principles apply to any other shaped area. In the case of balconies, at least 20% of the total wall area shall be and remain open and unrestricted. 630298_3 EF5000 Installation Guide - US...
  • Page 10: Corner Installations

    ” Dimensions of the cavity in this diagram represent the internal 13” size only. 65 ¾” Minimum clearance distance between adjacent wall and fascia to be no less than 11”. 630298_3 EF5000 Installation Guide - US...
  • Page 11: Laying Gas Pipe

    It is required by law that an approved shut off valve (not supplied) be installed in the line between the EF5000 Gas Fire and the gas supply. All hoses and gas pipes must be located out of pathways where people may trip over it and must not be in areas where the hose may be subject to accidental damage.
  • Page 12: Fixing The Fire Into The Cavity

    8.2. 10.1 The EF5000 must be isolated from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (14”WC).
  • Page 13 4. If no other adjustments are required, close the outlet pressure tap by turning the screw clockwise. Check all connections and pressure taps for leaks. 5. Finally, put the sticker supplied in the conversion kit onto the existing dataplate of the EF5000. 630298_3 EF5000 Installation Guide - US...
  • Page 14 The collars are located on the underside of the burners; a small screw must be removed to get the collar off. 13.5 Swapping to Propane Main Burner Jets Swap the main burner jets for those supplied in the conversion kit. 630298_3 EF5000 Installation Guide - US...
  • Page 15: Assembly Of Stone Cartridge

    14.1 With the glass in position, fix the stone cartridge to the fire by using the two supplied screws in the location shown below. Do this before the fascia is fitted. 630298_3 EF5000 Installation Guide - US...
  • Page 16: Fitting The Fascia

    Before fitting the fascia, the hooks must be attached using the screws provided. Ensure the two wires connecting the fascia to the fire are securely connected, as per section 11.0. The EF5000 Stainless Steel fascia is attached to the combustion box by four ‘hooks’ on the corners of the fascia.
  • Page 17 16.0 Placement of ceramic stones: EF5000 fuel beds should be evenly spread out with a maximum one layer of media. Do not heap or mound the fuel bed media, but attempt to get an even spread across the top of the burners.
  • Page 18: Operating Instructions

    17.0 Operating Instructions: The EF5000 is operated by the touch control panel located on the Right hand side outer edge of the fascia. The basic operations possible from the touch control are ON/OFF and manual adjustment of the flame height.
  • Page 19 17.7 Turning off the fire To turn the fire off, you must push the ON/OFF button this will shut down the gas flow to the pilot flame and both burners. 630298_3 EF5000 Installation Guide - US...
  • Page 20: Maintenance And Cleaning

    Ensure your strokes still follow the direction of the grain or brush finish. 6. Ensure that no film is applied to the glass of your Escea Gas Fireplace. If applied accidentally, wipe off with an absorbent microfibre cloth.
  • Page 21: Replacement Parts

    Replacement parts can be ordered by contacting info@escea.com 630298_3 EF5000 Installation Guide - US...
  • Page 22 High Pilot For certification inquires, please contact certinfo@csa-international.org or contact our Client Services Centre at 1.866.797.4272 or (416) 747-2661 CSA. Cleveland, Ohio 8501 East Pleasant Valley Road Cleveland, Ohio, USA, 44131-5575 630298_3 EF5000 Installation Guide - US...
  • Page 23 Where an Escea product is covered by a parts and labor warrantee, the warrantee covers both the repair by Escea of the defective part or the provision of a spare part to replace the defective part and the installation of that part.
  • Page 24 Provide us with reasonable proof of purchase for the Escea product; and 5.2.4 If required by us, provide us (or any person nominated by us) with access to the premises at which the Escea product is located at times nominated by us (so that we can inspect the Escea product).
  • Page 25 Where you make a claim under this warrantee, an authorized repairer may need to attend your premises to inspect the Escea product. We may charge you a service call fee if a repairer will be required to travel more than 30 miles from the nearest service centre to your location.
