Escea EF5000 Information For Builders & Architects

Hide thumbs Also See for EF5000:

Information for Builders & Architects

EF5000 – AUS

Important:

The appliance shall be installed in accordance with;

Local gas fitting regulations

Municipal building codes

NZ5261: 2003 Gas Installation, and AS 5601

Any other relevant statutory regulations.

TO BE INSTALLED ONLY BY AN AUTHORIZED PERSON

THIS APPLIANCE MUST NOT BE INSTALLED OR USED INDOORS

INSTRUCTIONS MUST BE LEFT WITH THE CONSUMER AND THE CONSUMER

TO RETAIN THEM FOR FUTURE REFERENCE.

Warning:

Installation of appliances fitted to fixed gas supply systems and repair of all appliances

must be carried out by a qualified service person.

A qualified service person should inspect and service this product at least annually.

This Gas Fire is for outdoor use only.

Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220, email:

For contact details of your local Escea distributor or dealer please visit

630106_1 Information for Builders & Architects EF5000 AUS

v 1.0

info@escea.net

www.escea.com

Table of Contents

Need help?

Do you have a question about the EF5000 and is the answer not in the manual?

Page 1 A qualified service person should inspect and service this product at least annually. This Gas Fire is for outdoor use only. Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220, email: info@escea.net For contact details of your local Escea distributor or dealer please visit www.escea.com...
Page 2 Gas Connection = Lower Left Rear Power Required: External power supply. Warning: Do not install a TV above this fire under any circumstances. Minimum Cavity Dimensions 1010 mm 585 mm 330 mm Clearances: 1010 1830 630106_1 Information for Builders & Architects EF5000 AUS...
Page 3 - Within a partial enclosure that includes an overhead cover and more than two walls, the following shall apply: At least 25% of the total wall area is completely open, and At least 30% of the remaining wall area is open and unrestricted 630106_1 Information for Builders & Architects EF5000 AUS...
