CSAT-5060 C-Band Transceivers
Appendix A
CSAT with Ethernet Remote Commands
Parameter
Command
Type
Retrieve Firmware
N/A
Number for the
Ethernet board
SNMP Read
SRC=
Community
SNMP
SSC=
System Contact
SNMP
SSL=
System
Location
SNMP
SSN=
Unit Name
SNMP Trap
STA=
Destination IP
Address 1
Arguments Description of arguments
variable length Query only
Returns the firmware type loaded into the unit.
Example:
>0001/FRM=
Boot:
FW-0000082;0.0.1a;04/09/08
Bulk1:
FW-0020597-;1.1.1 ;05/02/12
Bulk2:
FW-0020597-;1.1.1 ;05/02/12
Command or Query.
20 bytes,
characters, no
SNMP read community string. Empty string is not
spaces
allowed
Example: <1/SRC=public
20 bytes, Command or Query.
characters SNMP System Contact string.
Example: <1/SSC=Joe Net Admin.
If not configured it returns empty string: <1/SSC=
Command or Query.
20 bytes,
characters
SNMP System Location string
Example: <1/SSL=Upstairs back right.
If not configured it returns empty string. <1/SSL=
20 bytes, Command or Query.
characters
SNMP System Name string
Example: <1/SSN=Remote1.
If not configured it returns empty string. <1/SSC=
15 bytes, Command or Query.
Numerical
Used to set the IP address of the first SNMP Trap
destination IP Address 1 where traps will be sent where
the form xxx.xxx.xxx.xxx is the IP addresss
Example: <1/STA=010.006.030.001
When not configured, returns >0001/STA=0.0.0.0
Response to Command
N/A
SRC=
SRC?
SSC=
SSC?
SSL=
SSL?
SSN=
SSN?
STA =
STA?
A–24
Revision 1
MN/CSAT5060.IOM
Response to
Query
query
FRM=x
FRM?
See Note 2
SRC =x
SRC?
See Note 2
SSC =x [1..20]
SSC?
See Note 2
SSL =x [1..20]
SSL?
See Note 2
SSN =x [1..20]
SSN?
See Note 2
STA=xxx.xxx.xxx.x
STA?
xx
See Note 2
