Comtech EF Data CSAT-5060 Installation And Operation Manual page 206

C-Band Transceiver
CSAT-5060 100/125 Watt Installation
Item No.
1
2
3
4
5
6
Part No.
FP/BR0067
HW/M8FLATSS
HW/M8LOCKSS
HW/M8SPRINGNUT
HW/M8X1.25MMHEXSS
HW/M8X1.25X25HEXSS
Figure C-2. CSAT Mounting Brackets, AS/0415
Nomenclature
Bracket, Pole Mount Kit
Washer, Flat, M8 SS, Metric
Washer, Splitlock, M8, SS, Metric
Springnut, M8 xX 1.25
Bolt, Hex M8X1.25X16MM, SS
Bolt, Hexhead, M8X1.25X25, SS
C–4
Revision 1
MN/CSAT5060.IOM
QTY
2
8
8
4
4
4
