Addendum A. Ethernet-Based Remote Product Management - Comtech EF Data CSAT-5060 Installation And Operation Manual

Addendum A.
BASED REMOTE PRODUCT
AA.1 Introduction
Ethernet-based Remote Product Management of the unit is available using the J8 port.
To proceed with Ethernet-based Remote Product Management, make sure that:
•
The unit is operating with the latest version firmware files.
•
The unit is connected to a user-supplied Windows-based PC as follows:
•
•
•
See also the Remote Commands and Queries specifications tables found in Chapter 5.
SERIAL-BASED REMOTE PRODUCT MANAGEMENT.
The PC's Ethernet port is connected to the unit J8 port with RJ-45 cable.
The PC is running a terminal emulation program (for operation of the unit
remote control Telnet interface).
Use the remote serial query to find and record the IP Address.
ETHERNET-
MANAGEMENT
AA–1
