C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
tem No.
1
2
3
4
5
6
7
8
Figure A-15. 1:1 25W CSAT TX Switch Bracket, AS/0489
1
5
Part No.
FP/BR0080
HW/M4Flat
HW/M4LOCK
HW/M4X10PHP
HW/M8FLATSS
HW/M8LOCKSS
HW/M8SPRINGNUT
HW/M8X1.25X25HEXSS
A–14
8 7
Nomenclature
Bracket, Remote Coax Switch
Washer, Flat
Washer, Lock
Screw, Phillips Head 7X10
Washer, Flat SS
Washer, Split-Lock SS
Springnut
Bolt, Hex-Head SS
Revision 1
MN/CSAT5060.IOM
2,3
4
QTY
1
2
2
2
4
4
4
4
