CSAT-5060 C-Band Transceivers
Appendix A
CSAT Remote Commands
Parameter
Type Command Arguments
TX Slope Adjust USA= 3 bytes
RX Slope Mode DSM= 1 byte,
value of 0,1
RX Slope Adjust DSA= 3 bytes
Reference REF= 3 bytes
Oscillator Adjust
Cold Start CLD= 1 byte,
value of 0,1
Auto Fault AFR= 1 byte,
Recovery value of 0,1
Online Status 1 byte,
N/A
value of 0,1
Description of arguments
Command or Query.
TX Slope Adjust, between 0.0 and 1.0.
Resolution = 0.1.
Example: USA=0.3
Command or Query.
RX Slope Mode, where:
0 =Manual Mode,
1 = Calibrated Mode.
Example: DSM=1
Command or Query.
RX Slope Adjust, between 0.0 and 1.0.
Resolution = 0.1.
Example: DSA=0.3
Command or Query.
Ref Osc Adjust, between 000 and 255.
Resolution 001.
Example: REF=087
Note: REF cannot be adjusted when the CSAT
is locked to an external reference source.
Command or Query.
Cold Start, where:
0 = Disabled,
1 = Enabled
Example: CLD=1
Command or Query.
Auto Fault Recovery, where:
0 = Disabled,
1 = Enabled
Example: AFR=1
Query Only.
Online status, where:
0 = OFFLINE,
1 = ONLINE
Example: ONL=1
A–11
Response to Response to
Command Query Query
USA= (message ok) USA? USA=x.x
USA? (received ok, but
See Note 1
invalid arg. found)
DSM=(message ok) DSM? DSM=x
DSM?(received ok, But See Note 1
invalid argument found)
DSA= (message ok) DSA? DSA=x.x
DSA? (received ok, but See Note 1
invalid arg. found)
REF= (message ok) REF? REF=xxx
REF? (received ok, but See Note 1
invalid argument found)
REF* (message ok, but
not permitted in current
mode)
CLD= (message ok) CLD? CLD=x
CLD? (received ok, but See Note 1
invalid arguments
found)
AFR= (message ok) AFR? AFR=x
AFR? (received ok, but See Note 1
invalid arguments
found)
ONL= (message ok) ONL? ONL=x
ONL? (received ok, but
See Note 1
invalid arguments
found)
