Vicon V700-C Series Instruction Manual

Color dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL XX178-01
V700-C Series
COLOR DOME CAMERAS
About this manual
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for later reference.
This installation should be made by a qualified service person and should
conform to the National Electric Code, ANSI/NFPA 70 and all local codes.
Installers should use appropriate hardware mounting materials.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V700-C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon V700-C Series

Summary of Contents for Vicon V700-C Series

  • Page 1 INSTRUCTION MANUAL XX178-01 V700-C Series COLOR DOME CAMERAS About this manual Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for later reference. This installation should be made by a qualified service person and should conform to the National Electric Code, ANSI/NFPA 70 and all local codes.

  • Page 2: Fcc Notice

    FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.
  • Page 3 • Relocate the equipment away from the receiver. • Plug the equipment into a different electrical outlet so that the equipment and receiver are on different branch circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: “Interference Handbook, Bulletin CIB-2”...
  • Page 4 Dimensions : inch (mm) Surface-Mount configuration In-Ceiling configuration...
  • Page 5 PRECAUTIONS ■ Do not open or modify Do not open the case except during maintenance and installation, as it may be dangerous and cause damages. ■ Do not put objects inside the unit Make sure that no metal objects or flammable substances get inside the camera.

  • Page 6: Troubleshooting

    TROUBLESHOOTING Before sending the camera out for repair, check the items below. If the problem persists after checking these items, contact your service center. ■ If no image appears Is the coaxial cable attached securely? Are the power and voltage normal? Has the iris of the lens inside the camera been adjusted correctly (with the level volume) ? Is there adequate illumination?

  • Page 7: Lens Adjustment

    LENS ADJUSTMENT ROLL SET SCREW (2X) TILT ZOOM 90˚ FOCUS 1. Adjust the panning (360˚) and tilt (90˚) position. 2. Set the zoom position by using Zoom Lever Screw. 3. Set the focus by using Focus Lever Screw. 4. Loosen set screws (using small M1.0 Hex L-wrench provided) to adjust roll (turns camera position top/bottom).
  • Page 8 SPECIFICATION - V700-C SERIES General Spec NTSC CCD Type 1/3" 410K Pixels Color 1/3" 470K Pixels Color Total number of pixels 811(H) X 508 (V) 795(H) X 596(V) Min illumination 0.013 fc (0.14 Lux ) @ F1.2, 30IRE Video Output 1.0Vp-p/75 ohm Composite...
  • Page 9 CONNECTIONS 12VDC-24VAC RED (+) BLACK (-) VIDEO 11.8in (300mm) Cable for connection to portable monitor, provided. When using a portable monitor, terminate at 75ohms (at last device). 12VDC-24VAC RED (+) BLACK (-) VIDEO CAUTION The use of a UL Listed Class 2 power supply is required to ensure compliance with electrical safety standards.
  • Page 10 Surface-Mount Base In-Ceiling Base...

  • Page 11: Camera Settings

    CAMERA SETTINGS ■ CAMERA SETTINGS FOR V700-C SERIES FUNCTION OF CONTROL BOARD [1]. SW Functional control of O.S.D (On Screen Display) [2]. CON1 CON1 Second Video output connector CON2 [3]. CON2 RS-485 connector...
  • Page 12 ■ OSD MAP 1. EXPOSURE 6. PRIVACY LENS MASK 1 E. SHUTTER MASK 2 MASK 3 MAX_DR MASK 4 MASK 5 SENSE_UP MASK 6 2. COLOR 7. SYNC WB MODE SYNC MODE R-Y GAIN V_PHASE B-Y GAIN 3. DAY&NIGHT 8. SETUP D&N MODE CAMERA ID C-SUP...

  • Page 13: Installation

    INSTALLATION...
  • Page 14 The V700-C can be either mounted to a surface (like a ceiling or wall) or installed into the ceiling, with or without an electrical box. Use the large (Torx T20) L-Wrench to loosen the 4 screws (B) securing the dome assembly. For surface-mount installations, align the mounting base (D) with the mounting surface;...
  • Page 15 2 On Yiu Street, Shatin D-24537 Neumuenster New Territories, Phone: +49 (0) 4321 8790 Hong Kong Fax: +49 (0) 4321 879 97 (852) 2145-7118 Fax: (852) 2145-7117 Internet Address: www.vicon-cctv.com Vicon Part Number 8009-8178-01-00 Rev 310 © Copyright 2010, Vicon Industries Inc.
