INSTRUCTION MANUAL XX178-11
V700W Series
COLOR DOME CAMERAS
About this manual
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for later reference.
This installation should be made by a qualified service person and should conform
to the National Electric Code, ANSI/NFPA 70 and all local codes.
Installers should use appropriate hardware mounting materials.
Advertisement
Table of Contents
Related Manuals for Vicon V700W Series
Summary of Contents for Vicon V700W Series
- Page 1 INSTRUCTION MANUAL XX178-11 V700W Series COLOR DOME CAMERAS About this manual Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for later reference. This installation should be made by a qualified service person and should conform to the National Electric Code, ANSI/NFPA 70 and all local codes.
-
Page 2: Fcc Notice
FCC Notice Note: Complies with Federal Communications Commission Rules & RegulationsPart 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception. - Page 3 The user may find the following booklet prepared by the Federal Communications Commission helpful: “Interference Handbook, Bulletin CIB-2” This booklet is available from the U.S. Government Printing Office, Superintendent of Documents, Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1. Warning: Power must be removed from this unit before removing circuit modules or cables.
- Page 4 Dimensions : inch (mm) Surface-Mount configuration In-Ceiling configuration...
- Page 5 PRECAUTIONS ■ Do not open or modify Do not open the case except during maintenance and installation, as it may be dangerous and cause damages. ■ Do not put objects inside the unit Make sure that no metal objects or flammable substances get inside the camera.
-
Page 6: Troubleshooting
TROUBLESHOOTING Before sending the camera out for repair, check the items below. If the problem persists after checking these items, contact your service center. ■ If no image appears ▪ Is the coaxial cable attached securely? ▪ Are the power and voltage normal? ▪... -
Page 7: Lens Adjustment
LENS ADJUSTMENT ROLL SCREW (2X) TILT ZOOM 90˚ FOCUS 1. Adjust the panning (360˚) and tilt (90˚) position. 2. Set the zoom position by using Zoom Lever Screw. 3. Set the focus by using Focus Lever Screw. 4. Loosen set screws (using small M1.0 Hex L-wrench provided) to adjust roll (turns camera position top/bottom). - Page 8 SPECIFICATION - V700W-N General Spec NTSC CCD Type 1/3" 410K Pixels Color 1/3" 470K Pixels Color Total number of pixels 811(H) X 508 (V) 795(H) X 596(V) Min illumination 0.013 fc (0.14 Lux ) @ F1.2, 30IRE (at COLOR) 0.003fc (0.03 Lux ) @F1.2, 30IRE (at TDN(B/W)) Video Output 1.0Vp-p/75 ohm Composite Resolution...
- Page 9 SPECIFICATION - V700W-I General Spec NTSC CCD Type 1/3" 410K Pixels Color 1/3" 470K Pixels Color Total number of pixels 811(H) X 508 (V) 795(H) X 596(V) Min illumination 0.013 fc (0.14 Lux ) @ F1.2, 30IRE (at COLOR) 0.003fc (0.03 Lux ) @F1.2, 30IRE (at IR version)) Video Output 1.0Vp-p/75 ohm Composite Resolution...
- Page 10 SPECIFICATION - V700W-D General Spec NTSC CCD Type 1/3" WDR CMOS sensor Total number of pixels 742(H) X 552 (V) Min illumination 0.06 fc (0.6 Lux )(DSS on) @F1.2, 30IRE (at COLOR) 0.008 fc (0.08 Lux )(DSS on) @F1.2, 30IRE (at TDN(B/W)) Video Output 1.0Vp-p/75 ohm Composite Resolution...
- Page 11 CONNECTIONS CAUTION The use of a UL Listed Class 2 power supply is required to ensure compliance with electrical safety standards. Check for polarity when using a 12 VDC power supply. Cable for connection to portable monitor, provided. When using a portable monitor, terminate at 75 ohms (at last device).
- Page 12 In-Ceiling Base Surface-Mount Base...
-
Page 13: Camera Settings
CAMERA SETTINGS ■ CAMERA SETTINGS FOR V700W-N AND V700W-I CON1 CON2 FUNCTION OF CONTROL BOARD [1]. SW Functional control of O.S.D(On Screen Display) [2]. CON1 Second Video output connector [3]. CON2 RS-485 connector... - Page 14 CAMERA SETTINGS ■ CAMERA SETTINGS FOR V700W-D CON2 ① CON1 FUNCTION OF CONTROL BOARD [1]. SW Functional control of O.S.D(On Screen Display) [2]. CON1 Second Video output connector [3]. CON2 RS-232 connector(1:Rx, 2:Tx, 3:GDN)
- Page 15 ■ CAMERA SETTINGS FOR V700W-D (JST : BM14B-SRSS-TB(LF)(SN)) (JST : BM06B-SRSS-TB(LF)(SN)) NTSC/PAL (MOLEX : 53047-0410) NTSC...
- Page 16 ■ OSD MENU (V700W-N, V700W-I) 1. EXPOSURE 6. PRIVACY LENS MASK 1 E. SHUTTER MASK 2 MASK 3 MAX_DR MASK 4 MASK 5 SENSE_UP MASK 6 2. COLOR 7. SYNC WB MODE SYNC MODE R-Y GAIN V_PHASE B-Y GAIN 3. DAY&NIGHT 8.
- Page 17 ■ OSD MENU (V700W-D) MAIN MENU MANUAL LENS DC : LEVEL (Range +20 to -42) WDR BIAS : LEVEL (Range +20 to -20) WDR LIMIT: LEVEL (Range 0 to +36) WB CONTROL AWB : PUSH&LOCK MANUAL : LEVEL (Range 2,500K to 9,500K)) AGC BIAS : LEVEL (Range +18 to -18) AGC LIMIT: LEVEL (Range 0 to 40) LIMIT: LEVEL (Range 0 to 60)
-
Page 18: Installation
INSTALLATION... - Page 19 The V700W series can be either mounted to a surface (like a ceiling or wall) or installed into the ceiling, with or without an electrical box. Use the large (Torx T20) L-Wrench to loosen the 4 screws (B) securing the dome assembly.
-
Page 20: Corporate Headquarters
Phone: +49 (0) 4321 8790 Hong Kong Fax: +49 (0) 4321 879 97 (852) 2145-7118 Fax: (852) 2145-7117 Internet Address: www.vicon-cctv.com Vicon Part Number 8009-8178-11-00 Rev 310 © Copyright 2010, Vicon Industries Inc. Product specifications subject to change without notice.
