Automatic Grouping; Locking An Object In Place On A Page - SMART Notebook 10 User Manual

To lock an object in place
To lock an object but
allow its movement
To lock an object but
allow its movement
and rotation
To unlock an object
44 | CH A P T E R 8 – M AN I P U L A T I N G O B JE C T S O N A P A G E

Automatic Grouping

When you draw or write on an interactive screen, SMART Notebook automatically
groups the objects that you create in close proximity, enabling you to interact with
these objects as a single object. For example, if you write the letters of a word,
SMART Notebook groups the individual letters into a single object, allowing you to
interact with the whole word.
If SMART Notebook groups objects that you want to manipulate individually, ungroup
the objects, as described above.
TIP
If you want to write words on the same line but don't want SMART Notebook to
group them automatically, leave a large gap between them, use different pens or
put the pen back in the pen tray briefly before writing another word.

Locking an Object in Place on a Page

You can lock an object to prevent its modification, movement or rotation. You can
remove this lock at any time. Alternatively, you can lock an object to prevent its
modification and still allow its movement or movement and rotation.
1. Select the object or objects.
2. Press the object's menu arrow, and then select Locking > Lock in Place.
You're unable to move, rotate or modify the object until you unlock it.
1. Select the object or objects.
2. Press the object's menu arrow, and then select Locking > Allow Move.
You can move the object but you're unable to rotate or modify it until you unlock it.
1. Select the object or objects.
2. Press the object's menu arrow, and then select Locking > Allow Move and
Rotate.
You can move and rotate the object but you're unable to modify it until you unlock
it.
1. Select the object.
2. Press the object's lock icon and then select Unlock.
