To recalibrate the
position of the strip
12 1 | CH A PT ER 19 – T H E S M A R T N O T E BO O K C O N T R O L P A N E L
8. Press OK to confirm your selection.
NOTE
If your changes affect the size of the icon strip, you must recalibrate the
position of the icon strip.
9. Press OK to close the control panel.

Positioning the Icon Strip

If you set up a tool strip or custom icon strip, you can reposition these strips at any
time.
Position the icon strips on the left, right or bottom edge of the interactive product (in
the black border). Wherever you position it, make sure that the edge of the strip is
aligned with the frame of the interactive product. You must then recalibrate the
position of the strip.
1. Open the SMART Notebook control panel.
2. Press SMART Hardware Settings.
The upper area of the control panel displays an image of the SMART product
connected to the computer.
3. If your computer is connected to more than one SMART product, the upper area
of the control panel displays an image of each SMART product. Press the image
of the product with the settings you want to change.
4. Select Set Up Icon Strips in the list.
5. Select the icon strip you want to move.
6. Press Position Strip to display the calibration screen.
7. Follow the on-screen instructions to define the corners of the strip.
NOTE
If you press the interactive screen too far from the edge of the icon strip, an
error message appears and you must try again.
8. Press OK to close the control panel.
