Drawing Shapes On A Page - SMART Notebook 10 User Manual

To customize a shape and
then add it to a page
To draw a shape with
the Shape Recognition
Pen tool
32 | CH A P T E R 6 – C R E AT I N G O B J E C T S O N A P A G E
TIP
– You can create perfect circles, squares, triangles and other shapes by
pressing and holding SHIFT as you draw the shape.
– If the available shapes cover the area you want to place the object, press
Shapes
3. To customize the shape, select the shape, and then edit its properties.
1. Press Shapes , and then select an available shape.
2. If the Properties tab isn't visible, press Properties
3. Press Line Style.
4. Select the color, thickness and style for the shape's outline.
5. Press Fill Effects.
6. Select the transparency and fill effects for the shape.
NOTE
If you want to save this shape for future use, press Save Tool Properties.
7. Create a shape by pressing where you want to place the shape and dragging until
the shape is the size you want.
TIP
You can create perfect circles, squares, triangles and other shapes by
pressing and holding SHIFT as you draw the shape.

Drawing Shapes on a Page

You can use the Shape Recognition Pen tool to draw circles, ovals, squares,
rectangles, triangles and arcs.
1. Press Shape Recognition
2. Draw a shape on the interactive screen.
again to hide them.
.
.
