Orienting The Interactive Screen - SMART Notebook 10 User Manual

To orient the
interactive screen
To orient multiple
interactive screens
12 4 | CH A PT ER 19 – T H E S M A R T N O T E BO O K C O N T R O L P A N E L

Orienting the Interactive Screen

You must configure and align SMART Notebook to respond accurately when you
press the interactive screen. You can provide this information by performing an
orientation: a simple process of pressing firmly and precisely on a target displayed on
the screen.
Although the interactive screen is oriented by default, you can orient it again to ensure
precision.
1. Open the SMART Notebook control panel.
2. Press Orient/Align the SMART Product.
TIP
On some interactive whiteboards, you can press both pen tray buttons
simultaneously to start the orientation procedure.
Targets appear on the screen.
3. Press the center of each target in the order indicated on the screen. The computer
registers the point on the interactive whiteboard where you remove your finger or
pen from the screen surface.
The orientation procedure involves touching 4, 9, 12 or 20 targets, depending on
the orientation level you select.
NOTE
– To effectively orient the interactive screen, press an area near each
target, and then slide your finger or pen to the center each target's cross
hairs before removing it. Keep your finger or pen at a right angle to the
screen.
– You can reorient a target by pressing the two pen tray buttons
simultaneously or the LEFT ARROW key on the keyboard.
– If you want to close the orientation screen before finishing the orientation
procedure, press ESC. Otherwise, the orientation screen closes after you
press the last target.
If your computer is connected to more than one SMART product, you need to provide
further information to SMART Notebook so that it knows which interactive screen to
orient.
1. Open the SMART Notebook control panel.
2. Select SMART Hardware Settings.
