SPECIFICATIONS AND FEATURES

Operating frequencies:
Sensitivity:
Signal/noise ratio:
Squelch quieting:
AM rejection:
Modulation acceptance:
IF Selectivity:
Third order intercept:
Diversity technique:
Audio outputs:
Antenna inputs:
Controls:
Indicators:
Power requirements:
Power consumption:
Weight:
Dimensions:
Specifications subject to change without notice
150 to 216MHz, crystal controlled
-110dBm for 20dB Sinad (0.7uV)
96dB flat; 99dB A-weighted
Greater than 109dB
Below the noise at all input levels
Greater than ±15kHz
150kHz interference bandwidth; -30dB @ ±200kHz
+5dBm
Dual receiver "opti-blend" audio combining
XLR: 200 Ohm bal.; 100mV max.
Dual BNC female; 50 Ohm impedance
Front panel attenuator controls balanced outputs; Power switch
Red LED for power "ON"; Dual modulation LEDs show
transmitter audio level; Dual "opti-blend" LEDs display mixture
ratio; Code ON LED
12V DC (rear panel jack); 110V AC (using supplied CH-12
AC adapter)
170mA max
10.1 ozs
3¼" wide, 1¼" high, 5¼" deep
Rio Rancho, NM – USA
Ratio Diversity Receiver
