Zero Clearance Room
Sealed Gas Fireplace
STYLE
See Thru
PG121-NG
Left Corner
PG121LC-NG
Right Corner
PG121RC-NG
Pier
PG131-NG
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult an
authorised installer, service agency or the gas
supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
Installation and service must be performed by an
authorised installer, service agency or the gas
supplier.
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
918-367
MODEL
PG121-LPG
PG121LC-LPG
PG121RC-LPG
PG131-LPG
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical
switch: do not use any phone in
your building.
Immediately call your gas sup-
plier from a neighbour's phone.
Follow the gas supplier's in-
structions.
If you cannot reach your gas
supplier, call the fire depart-
ment.
Australia
P.O. Box 533
Braeside, Victoria, 3195
01/06/05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Masport PG121-NG
Summary of Contents for Masport PG121-NG
- Page 1 Owners & Installation Zero Clearance Room Sealed Gas Fireplace STYLE MODEL See Thru PG121-NG PG121-LPG Left Corner PG121LC-NG PG121LC-LPG Right Corner PG121RC-NG PG121RC-LPG Pier PG131-NG PG131-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, alteration,...
