Owners &
Installation
Baltimore
Gas Fires
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
For assistance or additional information
consult an authorized technichian, or your
Masport Gas Fire Dealer.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this appliance
Installation and service must be performed by
authorized personnel.
Metal Fab Industies Limited - New Zealand
PO Box 58 473
Greenmount
Auckland
FOR YOUR SAFETY
What to do if you smell gas
Do not try to light any
appliance
Do not touch any
electrical switch
Do not use any phone
in your building
Immediately close the
shutoff valve behind the
heater
Call the technician
Metal Fab PTY - Australia
Unit 2, 205 Abbotts Road
Dendenong South
Victoria 3175
591363

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BALTIMORE STD NG and is the answer not in the manual?

Questions and answers

Summary of Contents for Masport BALTIMORE STD NG

  • Page 1 For assistance or additional information • Do not touch any consult an authorized technichian, or your electrical switch Masport Gas Fire Dealer. • Do not use any phone FOR YOUR SAFETY in your building • Do not store or use gasoline or other...
  • Page 2 THE INSTRUCTIONS IN THIS MANUAL APPLY TO MASPORT BALTIMORE GAS FIRES. THE MODELS COVERED ARE:- For use with Natural Gas:- BALTIMORE STD NG, BALTIMORE ACC NG, BALTIMORE RMT NG, BALTIMORE ECS NG. For use with Liquid Propane Gas (LPG):- BALTIMORE STD LP,...
  • Page 3: Table Of Contents

    Statutory Regulations (e.g. AS 5601 (AG-601), NZS 5261). Any shortcomings in the appliance and flue installation will be the responsibility of the installer, and Masport Ltd will not be accountable for any such failings or their consequences.
  • Page 4: Operating Instructions

    OPERATING INSTRUCTIONS DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE. DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION. LIGHTING AND RUNNING THE FIRE:- •...
  • Page 5 When the wall mounted programmable thermostat is fitted – First ensure that good batteries (3 x AA alkaline) are fitted in the wall thermostat, that the slide switch behind the hinged bottom cover is set to ‘HEAT’, and that the temperature setting on the thermostat is above the prevailing room temperature.
  • Page 6 The IRRC Model 400 portable remote thermostat supplied with RMT models has two modes – MANUAL and AUTOMATIC. You can switch between these modes by pressing the small AUTO/MANU button after first pressing the large centre OFF/ON (OI) button to turn the control on. The control is ‘ON’ when the ‘flame’...
  • Page 7 lighting again. If you need to press the reset again, wait at least ten seconds before doing this. If there is a lot of air in the pipeline, it may be necessary to repeat this reset procedure several times. • When the pilot lights, the ECS system shuts down the ignition spark and then turns on the gas supply to the main burner.
  • Page 8: Cleaning Instructions

    CLEANING INSTRUCTIONS The outside of the cabinet and glass should need no more than an occasional wipe with a damp cloth to remove any dust which may have settled. All visible flame gas heaters can produce small amounts of soot, particularly if the combustion air entry slots under the heater are obstructed or the aeration air inlets are clogged with lint.
  • Page 9: Minimum Installation Clearances

    (To heat sensitive surfaces) NOTE: The clearances shown are for fire hazard only. For durability of finishes or surfaces you should contact the relevant manufacturer for their specification. MASPORT accepts no responsibility for the deterioration of surfaces or finishes. NO FLOOR PROTECTOR (HEARTH) IS REQUIRED...
  • Page 10: Thermostats

    THERMOSTATS ACC Models. Two accessory options are available: • The hand-held IRRC Model 300 non-programmable remote thermostat. • The wall-mounted programmable thermostat. Instructions for installing both options are supplied with them. RMT Models. These have an IRRC Model 400 programmable hand-held remote control (not interchangeable with the Model 300 control available for the ACC models).
  • Page 11: Fan

    Before setting the low pressure, remove one of the blue wires connected to the top of the modulating coil. There is no need to alter the handpiece control setting. Adjust the low pressure by rotating the central Phillips head screw, taking care not to shift the position of the already adjusted 10mm hex. nut. Screw down to increase the pressure.
  • Page 12: Seismic Restraint

    SEISMIC RESTRAINT New Zealand regulations require that flued gas heaters be secured to prevent shifting in the event of an earthquake. This is best done by fastening the heater to the floor right through the floor protector if one is fitted. Fasten with two screws not less than 12 gauge or the equivalent in coach screws or toggle fasteners.
  • Page 13: Maintenance Instructions

    If a wall mounted or remote thermostat is fitted, verify the thermostat action by turning the set temperature above and below the room ambient temperature to check that the burner turns on and off automatically. Hand held remote thermostats must point toward the receiver for effective operation. If a fan is fitted, check its operation at all speeds.
  • Page 14: Glass Removal And Assembly

    GLASS REMOVAL AND ASSEMBLY Carry out these procedures only while the heater is standing upright. 1. Remove the louvre by lifting it upwards and outwards. 2. Remove the dress guard, if fitted, by first removing the bottom panel of the cabinet. 3.
  • Page 15: Routine Maintenance

    This is not unique to Masport gas fires. If the surface discolours or blisters, simply scuff any loose paint from the firebox and lightly re-spray with Masport high temperature paint.
  • Page 16: Ecs Wiring Diagrams

    NOTE: If the supply cord is damaged it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
  • Page 17: Trouble Shooting

    TROUBLE - SHOOTING The following table lists possible problems and their likely causes. Most of these will require a professional serviceman and we recommend that this work be performed by an Authorised Technician. If a problem cannot be solved after referring to this table, please call the Retailer from whom the appliance was purchased. Refer to your Warranty Card for details of Warranty cover.
  • Page 18 PROBLEM POSSIBLE CAUSE(S) SOLUTION Smell of gas in the room. Pipe fittings may be leaking. Check all joints for leaks, including the gas supply system, the pilot light supply tube, the main burner supply tube and all connections to the control valve and pressure reducing valve (STD NG models).
  • Page 19: Annual Service Record

    ANNUAL SERVICE RECORD DATE SERVICE DETAILS SERVICED BY...
  • Page 20 Masport Gas Fires are manufactured in New Zealand by MASPORT LTD. 1/37 MT WELLINGTON HIGHWAY. P.O. Box 14-349 Panmure, Auckland New Zealand. A.G.A. Approvals: MG 5000 - 01 NG and MG 5000 - 01 LP — Certificate No 5656. Installed by:-...
