INSTALLATION SPECIFICATION SHEET
These instructions must be used in conjunction with the 'General Installation Instructions' for Masport
wood fires.
CLEARANCE REQUIREMENTS
This fire has been tested and complies to the Australian/New Zealand Standard AS/NZS 2918:2001 and all
installations must be in accordance with the minimum clearances to combustibles indicated in these instructions.
The minimum clearances to combustables may be reduced if the combustable walls are shielded with an approved
non-combustable material. Details of suitable materials and appropriate clearance reduction factors are present in
Section 3 of AS/NZS 2918:2001.
POSITIONING YOUR FREE-STANDING WOODFIRE
AUSTRALIA
MINIMUM DISTANCES TO HEAT SENSITIVE WALLS (mm)
MODEL
F10000 HW
F12000 HW
AIR-GROUP SPECIAL INSULATED FLUE KIT *
FAIRHAVEN
§ Valid only when the room walls are at 90° to each other.
‡ Note: Clearances are for fire hazard only. For durability of finishes or surfaces you should contact the relevant
manufacturer for their specification. Masport accepts no responsibility for the deterioration of surfaces or finishes.
* Air-Group Special Insulated Flue Kit is same as AHD Special Insulated Flue Kit.
FLUE HEAT SHIELD
FLOWMET UNIVERSL FLUE SYSTEM
MODEL
A
B
E
250
300
200
200
300
200
Page 1 of 5
F10000 HW
F12000 HW
FAIRHAVEN
F
G
H
445
680
607
395
680
607
595772
PRT. NO.
02.10.2017
DATE:
R§
858
858
Advertisement
Table of Contents
Related Manuals for Masport F10000 HW
Summary of Contents for Masport F10000 HW
-
Page 1: Clearance Requirements
‡ Note: Clearances are for fire hazard only. For durability of finishes or surfaces you should contact the relevant manufacturer for their specification. Masport accepts no responsibility for the deterioration of surfaces or finishes. * Air-Group Special Insulated Flue Kit is same as AHD Special Insulated Flue Kit. - Page 2 Flue MODEL Protector Type Ø Shield height 1160 F10000 HW 1110 F12000 HW FAIRHAVEN FUF = FLOWMET UNIVERSAL FLUE SYSTEM AGA = AIR GROUP / AHD SPECIAL INSULATED FLUE KIT WITH 900mm S/S REFLECTOR SHIELD AFP = ASH FLOOR PROTECTOR Ø...
- Page 3 Distance above PROTECTOR Shield Floor TYPE 1573 1347 F10000 HW 1573 1347 F12000 HW FAIRHAVEN FUF = FLOWMET UNIVERSAL FLUE SYSTEM AGA = AIR GROUP / AHD SPECIAL INSULATED FLUE KIT WITH 900mm S/S REFLECTOR SHIELD AFP = ASH FLOOR PROTECTOR...
- Page 4 FREE STANDING FIRE DIMENSIONS Seismic Restrain Holes Location MODEL F10000HW F12000HW FAIRHAVEN Seismic Restrain - In New Zealand and some part of Australia, it is required that the wood fire and floor protector are secured to prevent shifting in the event of an earthquake. This is best done by fastening the wood fire right through the protector to the floor, using two 8mm dynabolt or 8mm coach screws or toggle fasteners for wooden floors of appropriate length.
- Page 5 FOR AUS INSTALLATION WITH FLOMET UNIVERSAL FLUE SYSTEM, PLEASE REFER TO THE SPECIFIC FLUE INSTALLATION INSTRUCTIONS FROM FLUE MANUFACTURER. THE "AIR-GROUP SPECIAL INSULATED FLUE KIT" WHICH IS SAME AS "AHD SPECIAL INSULATED FLUE KIT" MUST BE MODIFIED AS PER DIAGRAM BELOW FOR F7000 HW 175MM FLUE KIT INSTALLATIONS IN AUSTRALIA.
