Microcom 424M Operator's Manual page 36

Chapter 3 Getting Started
C:\Program Files\MICOptions> micprint c:\temp\app1\image.bmp 0 –p08 –d "c:\\temp\\app1"
-f c:\temp\app1\app1.set
This example prints image.bmp on COMM 8 using the app1.set Micoptions configuration.
Please note that the supporting files are located at c:\temp\app.
By default, supporting files are located at the following locations:
WINDOWS XP
C:\Documents and Settings\All Users\Documents\MICPrinter
WINDOWS 7 32bit
C:\Users\Public\Documents\Micprinter
This is the location where the .set files should be copied so that the IMPORT may be
selected above to configure the printer.
It is also important to check the status of the application to make sure that the job printed
without issue.
You may use the Exit Code, %errorlevel%, to retrieve the return code from the Micprint
application.
Micprint status returns:
0 - success
-1 - unable to open image file
-2 - unknown image file type
-3 - unable to allocate memory
-4, -9, -10, -12, -13. -31 - unknown error
-5 - unsupported image resolution
-6 - error opening output file
-8 - error opening output file - binary form
-11 - image compression not supported
-14 - output width exceed maximum
-20 - binary image file not found
-21 - setting contrast error
-22 - setting dispense mode 0 error - no dispense mode sent
-23 - setting dispense mode 1 error - advance when idle
-24 - setting dispense mode 2 error - advance every label
-25 - setting dispense mode 3 error - cut every label
-26 - setting retraction delay error
-27 - setting dispense distance error
-29 - low stock prior to printing
-30 - low stock detected post printing
-40 - pre-print command string error
-41 - pre-print command file error
-42 - post-print command string error
-43 - post-print command file error
-50 - sending file format error
-60 - binary file download error
324M/424M Operator's Manual - 880026-0144 3-19
