Protocol Handler Services

In the abstract, a protocol consists of a 128-bit guaranteed unique identifier (GUID) and a Protocol
Interface structure. The structure contains the functions and instance data that are used to access a
device. The functions that make up Protocol Handler Services allow applications to install a
protocol on a handle, identify the handles that support a given protocol, determine whether a handle
supports a given protocol, and so forth. See Table 3-7.
Table 3-7.

Protocol Interface Functions

Name
InstallProtocolInterface
UninstallProtocolInterface
ReinstallProtocolInterface
RegisterProtocolNotify
LocateHandle
HandleProtocol
LocateDevicePath
As depicted in Figure 3-1, the firmware is responsible for maintaining a "data base" that shows
which protocols are attached to each device handle. (The figure depicts the "data base" as a linked
list, but the choice of data structure is implementation-dependent.) The "data base" is built
dynamically by calling the InstallProtocolInterface()function. Protocols can only be
installed by EFI drivers or the firmware itself. In the figure, a device handle (EFI_HANDLE) refers
to a list of one or more registered protocol interfaces for that handle. The first handle in the system
has four attached protocols, and the second handle has two attached protocols. Each attached
protocol is represented as a GUID / Interface pointer pair. The GUID is the name of the protocol,
and Interface points to a protocol instance. This data structure will typically contain a list of
interface functions, and some amount of instance data.
Access to devices is initiated by calling the
whether a handle supports a given protocol. If it does, a pointer to the matching Protocol Interface
structure is returned.
When a protocol is added to the system, it may either be added to an existing device handle or it
may be added to create a new device handle. Figure 3-1 shows that protocol handlers are listed for
each device handle and that each protocol handler is logically an EFI driver.
