All EFI GUIDs (Globally Unique Identifiers) have the format described in Appendix J of the
Wired for Management Baseline Specification. This document references the format of the GUID,
but implementers must reference the Wired for Management specifications for algorithms to
generate GUIDs. The following table defines the format of an EFI GUID (128 bits).
Table A-1.
EFI GUID Format
Mnemonic
TimeLow
TimeMid
TimeHighAndVersion
ClockSeqHighAndReserved
ClockSeqLow
Node
All EFI time is stored in the format described by Appendix J of the Wired for Management
Baseline Specification. While this is the appendix for GUID it defines a 60-bit timestamp format
that is used to generate the GUID. All EFI time information is stored in 64-bit structures that
contain the following format: The timestamp is a 60-bit value that is represented by Coordinated
Universal Time (UTC) as a count of 100-nanosecond intervals since 00:00:00.00, 15 October 1582
(the date of Gregorian reform to the Christian calendar). This time value will not roll over until the
year 3400 AD. It is assumed that a future version of the EFI specification can deal with the
year-3400 issue by extending this format if necessary.
Version 1.02
GUID and Time Formats
Byte
Byte
Offset
Length
Description
0
4
The low field of the timestamp.
4
2
The middle field of the timestamp.
6
2
The high field of the timestamp multiplexed with the
version number.
8
1
The high field of the clock sequence multiplexed with
the variant.
9
1
The low field of the clock sequence.
10
6
The spatially unique node identifier. This can be
based on any IEEE 802 address obtained from a
network card. If no network card exists in the system,
a cryptographic-quality random number can be used.
12/12/00
A
331
