5.3
Device Path Nodes
There are six major types of Device Path nodes:
•
Hardware Device Path. This Device Path defines how a device is attached to the resource
domain of a system, where resource domain is simply the shared memory, memory mapped
I/O, and I/O space of the system.
•
ACPI Device Path. This Device Path is used to describe devices whose enumeration is not
described in an industry-standard fashion. These devices must be described using ACPI
AML in the ACPI name space; this Device Path is a linkage to the ACPI name space.
•
Messaging Device Path. This Device Path is used to describe the connection of devices
outside the resource domain of the system. This Device Path can describe physical
messaging information (e.g., a SCSI ID) or abstract information (e.g., networking protocol
IP addresses).
•
Media Device Path. This Device Path is used to describe the portion of a medium that is
being abstracted by a boot service. For example, a Media Device Path could define which
partition on a hard drive was being used.
•
BIOS Boot Specification Device Path. This Device Path is used to point to boot legacy
operating systems; it is based on the BIOS Boot Specification Version 1.01.
•
End of Hardware Device Path. Depending on the Sub-Type, this Device Path node is used
to indicate the end of the Device Path instance or Device Path structure.
5.3.1
Generic Device Path Structures
A Device Path is a variable-length binary structure that is made up of variable-length generic
Device Path nodes. Table 5-1 defines the structure of a such a node and the lengths of its
components. The table defines the type and sub-type values corresponding to the Device Paths
described Section 5.3; all other type and sub-type values are Reserved.
Table 5-1.
Generic Device Path Node Structure
Mnemonic
Type
Sub-Type
Length
Specific Device Path Data
Version 1.02
Byte
Byte
Offset
Length
Description
0
1
Type 0x01 – Hardware Device Path
Type 0x02 – ACPI Device Path
Type 0x03 – Messaging Device Path
Type 0x04 – Media Device Path
Type 0x05 – BIOS Boot Specification Device Path
Type 0xFF – End of Hardware Device Path
1
1
Sub-Type – Varies by Type. (See Table 5-2.)
2
2
Length of this structure in bytes. Length is 4 + n bytes.
4
n
Specific Device Path data. Type and Sub-Type define
type of data. Size of data is included in Length.
12/12/00
Device Path Protocol
119
