Table C-1.
Legacy Floppy Device Path
Byte
Byte
Offset
Length
0
1
1
1
2
2
4
4
8
4
C
1
D
1
E
2
10
1
11
1
12
1
13
1
14
2
16
4
1A
4
1E
1
1F
1
20
2

C.3 IDE Disk

The IDE Disk controller is a PCI device that is contained in a function of the root PCI host bridge.
The root PCI host bridge is a multi function device and has a separate function for chipset registers,
USB, and IDE. The disk connected to the IDE ATA bus is defined as being on the primary or
secondary ATA bus, and of being the master or slave device on that bus.
In ACPI this configuration is represented in the _SB, system bus tree, of the ACPI name space.
PCI0 is a child of _SB and it represents the root PCI host bridge. The IDE controller appears to the
system to be a PCI device with some legacy properties, so it is represented as a child of PCI0 with
the name IDE0. PRIM is a child of IDE0 and it represents the primary ATA bus of the IDE
controller. MAST is a child of PRIM and it represents the that this device is the ATA master
device on this primary ATA bus.
Version 1.02
Data
Description
0x02
Generic Device Path Header – Type ACPI Device Path
0x01
Sub type – ACPI Device Path
0x0C
Length
0x41D0,
_HID PNP0A03 – 0x41D0 represents a compressed string 'PNP' and is in
the low order bytes
0x0A03
0x0000
_UID
0x01
Generic Device Path Header – Type Hardware Device Path
0x01
Sub type PCI Device Path
0x06
Length
0x00
PCI Function
0x10
PCI Device
0x02
Generic Device Path Header – Type ACPI Device Path
0x01
Sub type – ACPI Device Path
0x0C
Length
0x41D0,
_HID PNP0303
0x0303
0x0000
_UID
0xFF
Generic Device Path Header – Type End Device Path
0xFF
Sub type – End Device Path
0x04
Length
12/12/00
Device Path Examples
339
