Extensible Firmware Interface Specification
G.4.7
Initialize
This command resets the network adapter and initializes UNDI using the parameters supplied in the
CPB. The Initialize command must be issued before the network adapter can be setup to transmit
and receive packets. This command will not enable the receive unit or external interrupts.
Once the memory requirements of the UNDI are obtained by using the Get Init Info command, a
block of kernel (non-swappable) memory may need to be allocated. The address of this kernel
memory must be passed to UNDI using the Initialize command CPB. This memory is used for
transmit and receive buffers and internal processing.
Initializing the network device will take up to four seconds for most network devices and in some
extreme cases (usually poor cables) up to twenty seconds.
G.4.7.1
Issuing the Command
To issue an Initialize command, create a CDB and fill it in as shows in the table below:
CDB Field
How to initialize the CDB structure for an Initialize command
OpCode
PXE_OPCODE_INITIALIZE
OpFlags
Set as needed.
CPBsize
sizeof(PXE_CPB_INITIALIZE)
DBsize
sizeof(PXE_DB_INITIALIZE)
Address of a
CPBaddr
Address of a
Dbaddr
StatCode
PXE_STATCODE_INITIALIZE
StatFlags
PXE_STATFLAGS_INITIALIZE
A valid interface number from zero to !PXE.IFcnt.
Ifnum
Control
Set as needed.
OpFlags
Ccable detection can be enabled or disabled by setting one of the following OpFlags:
PXE_OPFLAGS_INITIALIZE_CABLE_DETECT
PXE_OPFLAGS_INITIALIZE_DO_NOT_DETECT_CABLE
430
structure.
PXE_CPB_INITIALIZE
structure.
PXE_DB_INITIALIZE
12/12/00
Version 1.02
