Connector Pin Outs:
Connecting the DVR Power Cord
Connect the connector of the adaptor to the DVR, and connect the AC power cord to the adaptor and then
to the wall outlet.
WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD.
MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE.
DO NOT INSTALL POWER CORDS UNDER RUGS OR CARPET.
THE POWER CORD HAS A GROUNDING PIN. IF YOUR POWER OUTLET DOES NOT HAVE
A GROUNDING PIN RECEPTACLE, DO NOT MODIFY THE PLUG. DO NOT OVERLOAD THE
CIRCUIT BY PLUGGING TOO MANY DEVICES IN TO ONE CIRCUIT.
CAUTION: Ensure the DVR is not near any heat source that could cause overheating.

FRONT PANEL CONTROLS

HDD LED
NOTE: The infrared sensor on the DVR is just to the left of the HDD LED. Make certain that nothing blocks the
sensor, or the remote control will not function properly.
NOTE: When you use wireless communication devices (such as Wi-Fi or Bluetooth) near the DVR, the remote
control might not function properly.
HDD LED
The HDD LED flickers when the DVR is recording or searching video on the hard disk drive.
Power LED
The power LED is lit when the unit is On.
Alarm LED
The Alarm LED is lit when alarm output or internal buzzer is activated.
Master Unit
+ → To
–
→ To
GND
→ To
Power LED
16 Channel Digital Video Recorder
Slave Unit
→ TX+/RX+
→ TX-/RX-
→ GND
Alarm LED USB Port
5
