BEFORE LIGHTING
Important! Before Lighting...
Check the gas supply line for cuts, wear or abrasion.
Always keep your face and body as far away from the
grill as possible when lighting.
GRILL BURNER LIGHTING
This unit comes equipped with (2) electronic igniters.
The electronic igniter located on the right shelf lights
the side burner. The electronic igniter on the left shelf
lights the main burners, which are controlled by knobs
1, 2, 3, 4 & 5 and the back infrared burner.
LIGHTING THE GRILL WITH ELECTRONIC IGNITERS
Always open the lid before attempting lighting. Push
and turn one of the control knobs counter clockwise to
the "HIGH" position and immediately press the elec-
tronic igniter button. You'll hear a snapping sound. It
may be necessary to hold the electronic starter button
for about 4 seconds. If the burner does not light in 4
seconds, turn the knob to OFF and wait 5 minutes
before trying again. Repeat above steps to light
remaining burners. (See Fig. 15)
MATCH LIGHTING
If by chance the electronic igniter does not light the
burner, the burner may be lit with a match. Attach the
match to the match extender, located inside the right
cart door.
Keep your face as far away from the grill surface as pos-
sible and pass the match extender through the spaces
in the grill grates to the ports of the back crossover
burner between the flavor grids. Position the match
near the burner ports, then push and turn the control
knob counter clockwise to the "HIGH" position. (See Fig.
16-17)
NOTE: If the grill will not light after several attempts
see the trouble-shooting section of this manual. Turn
CONTROL KNOB LAYOUT:
The control knob bezel has
stamped markings for the HIGH
and LOW settings. Turning the
knob so the arrow faces the left
is the HIGH setting. Turning the
knob so the arrow faces down
is the LOW setting.

Lighting the Grill

H
L
Do not attempt to
"Light" the grill if the
odor of gas is present!!
Back
Knob
Knob
Infrared
#5
#4
Left electronic igniter
for main burners #1, #2,
#3, #4, #5 and back
infrared burner
Crossover Burner
Knob
Knob
Knob
#3
#2
#1
Right electronic
igniter for side
burner
Fig. 15
Fig. 16
Fig. 17
12
