JENN-AIR
30" AND 36" (76.2 CM AND 91.4 CM)
WALL-MOUNT CANOPY RANGE HOOD/
HOTTE DE CUISINIÈRE POUR MONTAGE MURAL
30" ET 36" (76,2 CM ET 91,4 CM)
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service in the U.S.A., call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca.
Instructions d'installation et Guide d'utilisation et d'entretien
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web à www.jennair.ca.
Table of Contents/Table des matières2
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
IMPORTANT : LIRE ET CONSERVER CES INSTRUCTIONS.
POUR UTILISATION RÉSIDENTIELLE UNIQUEMENT.
W10134195

Advertisement

Table of Contents
loading

Related Manuals for Jenn-Air WALL-MOUNT CANOPY RANGE HOOD

Summary of Contents for Jenn-Air WALL-MOUNT CANOPY RANGE HOOD

  • Page 1 ® JENN-AIR 30" AND 36" (76.2 CM AND 91.4 CM) WALL-MOUNT CANOPY RANGE HOOD/ HOTTE DE CUISINIÈRE POUR MONTAGE MURAL 30" ET 36" (76,2 CM ET 91,4 CM) Installation Instructions and Use & Care Guide For questions about features, operation/performance, parts, accessories, or service in the U.S.A., call: 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE DES MATIÈRES RANGE HOOD SAFETY ..............2 INSTALLATION REQUIREMENTS ..........4 Tools and Parts ................4 Location Requirements ..............4 Venting Requirements..............5 Electrical Requirements ...............6 INSTALLATION INSTRUCTIONS ..........7 Prepare Location................7 Install Range Hood...............8 Connect Vent System ..............8 Make Electrical Connection ............9 Install Vent Covers ..............10 Install Filters................10 Complete Installation ..............10...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF A RANGE TOP WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC GREASE FIRE: SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may Use this unit only in the manner intended by the ignite.

  • Page 4: Installation Requirements

    INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. 8 - 3.5 x 9.5 mm screws Read and follow the instructions provided with any tools listed 2 - 6 x 70 mm screws here. 6 - 5 x 35 mm mounting screws Tools needed 2 - 10 x 70 mm drywall anchors Level...

  • Page 5: Venting Requirements

    Cold weather installations Installation Dimensions An additional back draft damper should be installed to minimize backward cold air flow and a thermal break should be installed to minimize conduction of outside temperatures as part of the vent 10" (25.4 cm) system.

  • Page 6: Electrical Requirements

    Calculating Vent System Length Electrical Requirements Observe all governing codes and ordinances. To calculate the length of the system you need, add the Ensure that the electrical installation is adequate and in equivalent feet (meters) for each vent piece used in the system. conformance with National Electrical Code, ANSI/NFPA 70 (latest Vent Piece 8"...

  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Prepare Location It is recommended that the vent system be installed before 8. Mark centers of the 6 fastener locations through the template hood is installed. to the wall. IMPORTANT: All screws must be installed into wood. Before making cutouts, make sure there is proper clearance within the ceiling or wall for exhaust vent.

  • Page 8: Install Range Hood

    Non-Vented (recirculating) Installations Install Range Hood 1. Connect the deflector to the vent cover bracket using 4 - 3.5 WARNING x 9.5 sheet metal screws provided. Excessive Weight Hazard Use two or more people to move and install range hood. Failure to do so can result in back or other injury.

  • Page 9: Make Electrical Connection

    4. Run 3 wires, black, white and green (14AWG), in ¹⁄₂" conduit For Vented Installations Only: from service panel to terminal box. Use caulking to seal 1. Fit vent system over transition piece. opening. 2. Seal connection with clamps. 3. Check that backdraft dampers work properly. For Non-vented (recirculating) Installation Only: 1.

  • Page 10: Install Vent Covers

    7. Pull filter toward the front and insert into front channel. Install Vent Covers When using both upper and lower vent covers, push lower cover down onto hood and lift upper cover to ceiling and install with two 2.9 x 6.5 mm screws. NOTE: Upper vent cover may be reversed to hide slots.

  • Page 11: Range Hood Care

    RANGE HOOD CARE Cleaning IMPORTANT: Clean the hood and grease filters frequently according to the following instructions. Replace grease filters before operating hood. Be sure lights are cool before cleaning the hood. Exterior Surfaces Clean the range hood with a mild detergent and soft cloth. Do not use abrasive cleanser or steel-wool pads.

  • Page 12: Wiring Diagram

    WIRING DIAGRAM COLOR TABLE COLOR TABLE MOTOR CONNECTIONS SPEED TO TERMINALS BLACK BLUE WHITE SE1Q7A BLUE - WHITE BROWN YELLOW GREEN YELLOW/GREEN BLUE - RED GREY BLUE - BLACK WIRING BOX Fan Speed Cont. Brd (FSCB) Light Cont. Brd (LCB) SPEED 8-10 CONTACT...

  • Page 13: Assistance Or Service

    Call the dealer from whom your appliance was purchased, or call Jenn-Air at 1-800-807-6777 to locate an authorized service In the U.S.A. company. When calling, please know the purchase date and the complete model and serial number of your appliance.

  • Page 14: Warranty

    YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE. Outside the 50 United States and Canada, this warranty does not apply. Contact your authorized Jenn-Air dealer to determine if another warranty applies.
