SPECIFICATIONS

D General
• Frequency coverage:
Receive
Transmit
• Mode:
AUS versions
Other versions
• No. of memory Ch.:
• Usable temp. range: –30˚C to +60˚C;
• Frequency stability:
• Antenna impedance: 50 Ω
• Power supply:
AUS versions
Other versions
• Current drain:
Transmit
Receive
• Dimensions (projections are not included):
Main/Front package 62(H)×174(W)×259(D) mm
• Weight (approximately):
Main/Front package 3.9 kg, 8.6 lb
80
All stated specifications are typical and subject to change without notice or obligation.
0.5–29.9999 MHz
1.6–29.9999 MHz
J3E (USB), A3E (AM) RX only
J3E (USB/LSB), A3E (AM)
A1A (CW), F1B (FSK),
J2B (D1, D2, D3)
500 channels (maximum)
–22°F to +140°F
±0.3 ppm (–30˚C to +60˚C;
–22°F to +140°F)
13.8 V DC (negative ground)
10.8–15.6 V DC
11.73–15.87 V DC
Less than 28 A
(at maximum power)
Less than 3.0 A
(at maximum audio)
2.4(H)×6.9(W)×10.2(D) in
D Transmitter
• Output power (typical):
AUS versions
J3E HIGH 100 W p-p
MID
LOW
Other versions
J3E/A1A HIGH 125 W p-p
MID
LOW
A3E HIGH 30 W Carrier
MID
LOW
F1B/J2B HIGH 75 W p-p
MID
LOW
• Spurious emission:
USA versions 64 dB
below peak output power
Other versions 64 dB (typical)
below peak output power
• Carrier suppression: 50 dB
below peak output power
• Unwanted sideband suppression:
400 Hz 55 dB
below peak output power
1 kHz 65 dB
below peak output power
• Duty cycle:
Normal conversation 100% (–30˚C to +60˚C;
Continuous Data mode 25% (–30˚C to +30˚C;
All mode with Fan (CFU-F8100) is active
100% (–30˚C to +45˚C;
D Receiver
• Sensitivity:
J3E (Pre Amp ON)
(0.5–1.5999 MHz) 14 dBµV (10 dB S/N)
(1.6–29.9999 MHz) –14 dBµV (10 dB S/N)
A3E
(0.5–1.5999 MHz) 22 dBµV (10 dB S/N)
(1.6–29.9999 MHz) 6 dBµV (10 dB S/N)
• Spurious response rejection ratio:
More than 70 dB
• AF output power (at 13.8 V DC):
More than 4.0 W at 10%
distortion with a 4 Ω load
• Clarifier range: ±200 Hz
50 W p-p
10 W p-p
50 W p-p
10 W p-p
12.5 W Carrier
3 W Carrier
50 W p-p
10 W p-p
–22°F to +140°F)
–22°F to +86°F)
–22°F to +113°F)
