- Page 1 High Resolution / Day&Night COLOR BOX CAMERA MANUAL 사용 설명서 용 서 680 TVL...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
■ Contents 1.Features --------------------------------- 5 2. Components --------------------------------- 6 3. Names and functions of parts --------------------------------- 7 4. Installation --------------------------------- 9 5. Setup Menu Operation --------------------------------- 13 6. Troubleshooting --------------------------------- 21 7. Specifications --------------------------------- 22... -
Page 5: Features
1. Features ■SONY 1/3" 480K/570K-Effective Pixel Ex-view HAD CCD II Minimum Resolution 0.1 Lux (F1.2, 50 IRE) ■High Resolution: More than 680 TV Lines This camera has realized high resolution of 680 TV lines using the top-notch full digital image processing, 12 Bit A/D serial signal processing and special algorithm technologies. ■NR (Digital Noise Reduction) The DNR technology eliminates noise thus generating a distinct and clear image. -
Page 6: Components
2. Components COLOR CAMERA ------------- AUTO IRIS LENS CONNECTION ------------- PLUG C-MOUNT ADAPTOR ------------- L-WRENCH ------------- MANUAL -------------... -
Page 7: Names And Functions Of Parts
3. Names and Functions of Parts 1) Front ① Lens protection cap Please cover the lens when not using it. ② CS-Mount lens adaptor Please attach the CS-Mount lens here. ③ Back Focus clamp screw Please loosen the clamp screw with a screwdriver before adjusting the Back Focal length. - Page 8 2) Back ① Auto iris lens connector This is the connection terminal for the auto iris lens. ② Video output terminal Sends video signals and connects to the video input terminal of the monitor. ③ Power lamp Lights up when the correct power is supplied to the camera. ④...
-
Page 9: Installation
4. Installation 1) Lens Lenses are sold separately. Lenses such as auto iris lens, CS-Mount lens and C-Mount lens can be used. Note) • Use of the DC auto iris lens is recommended to achieve the best results for operating this product effectively. - Page 10 Please replace the auto iris lens connection plug cover and take off the lens protection cap, and then attach the auto iris lens to the camera by screwing it in clockwise. Please insert the connection plug that is connected to the auto iris lens cable into the auto lens connector, which is located on the back of the camera Please set the lens selection switch, located on the back of the camera, to DC or VIDEO depending on the type of auto iris lens which is being used.
- Page 11 ② When using a CS-Mount lens Please take off the lens protection cap and attach the CS-Mount lens to the camera by screwing it in clockwise. ③ When using a C-Mount lens Please take off the lens protection cap and attach the C-mount adaptor. Please attach the C-Mount lens to the camera by screwing it in clockwise.
- Page 12 malfunction. Please use a lens that weighs less than 450g. 2) Connecting to a monitor Please connect the video output terminal located on the back of the camera to the monitor. • The connection method varies depending on the type of monitor and accessories. Please refer to the user's manual for each instrument.
-
Page 13: Setup Menu Operation
5. Setup Menu Operation •Please press the SETUP button to set OSD menu. The SETUP menu is displayed like under the picture on the monitor. • if it has been selected. You may move up/down to use another function by up/down buttons and change the status by pressing left/right buttons. - Page 14 •AUTO (HIGH LUMINANCE) - AUTO IRIS Select this to control the shutter speed automatically. -SHUT+AUTO IRIS Select AE control on the medium and high brightness side -Brightness Select the high and medium brightness side reference (LOW LUMINANCE) -AGC Select AE control on the low-brightness side -Brightness Select the low brightness side reference •MANUAL...
- Page 15 •ATW - SPEED Adjusts the pull-in speed ATW - DELAY CNT Sets the time-based hysteresis of ATW - ATW FRAME Sets the pull-in frame magnification - ENVIROMENT Sets the pull-in frame(indoor/outdoor)of ATW •USER1 - B-GAIN Used for operating the B gain in the WB fixed gain mode -R-GAIN Used for operating the R gain in the WB fixed gain...
- Page 16 BACKLIGHT SETUP MENU •OFF LENS AUTO Backlight compensation OFF SHUTTER/AGC AUTO •BLC WHITE BAL BACKLIGHT Backlight compensation ON PICT ADJUST •HLC MOTION DET High light compensation ON NEXT EXIT SAVE ALL PICT ADJUST SETUP MENU LENS AUTO SHUTTER/AGC AUTO WHITE BAL BACKLIGHT PICT ADJUST MOTION DET...
- Page 17 •LUMINANCE Sets the extent of the luminance compression (LOW/MID/HIGH) •CONTRAST Sets the extent of the contrast enhancement (LOW/MIDDLE/MID/MIDHIGH/HIGH) MOTION DET SETUP MENU LENS AUTO SHUTTER/AGC AUTO WHITE BAL BACKLIGHT PICT ADJUST MOTION DET NEXT EXIT SAVE ALL •DETECT SENSE: Sets the motion detection sensitivity •BLOCK DISP OFF: Controls the ON/OFF status of the motion detection block display •BLACK DISP ENABLE: The display switches to the "dead band setting"...
- Page 18 •RIGHT Sets the right side of the monitoring frame selected by the AREA SEL parameter PRIVACY SETUP MENU PRIVACY DAY/NIGHT AUTO CAMERA ID SYNC LANGUAGE ENGLISH CAMERA RESET BACK EXIT SAVE ALL •AREA SEL: Selects the mask frame to be adjusted •TOP: Sets the top side of the mask frame selected by the AREA SEL parameter •BOTTOM: Sets the bottom side of the mask frame selected by the AREA SEL parameter.
- Page 19 -BURST Burst signal OFF enable, Burst signal ON -DELAY CNT Sets the Night/Day identification transfer time -DAY→NIGHT Set the threshold for identifying the Night status from the Day status. -NIGHT→DAY Set the threshold for identifying the Day status from the Night status. •B/W -BURST Burst signal OFF enable, Burst signal ON...
- Page 20 CAMERA ID SETUP MENU The function is used to set the camera ID PRIVACY •ON DAY/NIGHT AUTO Camera ID display OFF CAMERA ID •OFF SYNC Camera ID display ON LANGUAGE ENGLISH CAMERA RESET BACK EXIT SAVE ALL •↑↓→ ← The camera ID cursor moves •CLR The character selected by the camera ID cursor is cleared...
-
Page 21: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Problems Troubleshooting Nothing appears on the screen. • Please check the power connection. • Please check the video signal line connection. The video image is not clear. -
Page 22: Specifications
7. Specifications SIGNAL SYSTEM NTSC IMAGE SENSOR Sony 1/3" 480K/570K-Effective Ex-view HAD CCD Ⅱ TOTAL Pixels 1020(H) × 596(V) 1020(H) × 596(V) Effective Pixels 976(H) × 494(V) 976(H) × 582(V) RESOLUTION 680 TV lines Syns. Inter. H/V 15.734/ 59.94Hz 15.625K/50Hz Shutter Speed 1/60~1/100,000 sec 1/50~1/100,000 sec...
