Summary of Contents for D-MAX 650 TVL
- Page 1 High Resolution / Day&Night COLOR BOX CAMERA MANUAL 사용 설명서 용 서 650 TVL...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
■ Contents --------------------------------- 1.Features --------------------------------- 2. Components --------------------------------- 3. Names and functions of parts --------------------------------- 4. Installation --------------------------------- 5. Setup Menu Operation --------------------------------- 6. Troubleshooting --------------------------------- 7. Specifications... - Page 5 1. Features ☺Horizontal Resolution 650 TVLines Clear image quality has been achieved by employing a SONY CCD with 410,000 pixels, which provides a horizontal resolution of 620 TV lines. ☺DAY & NIGHT This camera has a function that automatically selects the mode that is appropriate for daytime or night-time conditions The COLOR mode operates in daytime conditions to provide optimum colors, and BW mode operates in nighttime conditions to enhance the definition of the image.
-
Page 6: Components
2. Components COLOR CAMERA ------------- AUTO IRIS LENS CONNECTION ------------- PLUG C-MOUNT ADAPTOR ------------- L-WRENCH ------------- MANUAL -------------... -
Page 7: Names And Functions Of Parts
3. Names and Functions of Parts 1) Front ① Lens protection cap Please cover the lens when not using it. ② CS-Mount lens adaptor Please attach the CS-Mount lens here. ③ Back Focus clamp screw Please loosen the clamp screw with a screwdriver before adjusting the Back Focal length. - Page 8 2) Back ⑥ ① Auto iris lens connector This is the connection terminal for the auto iris lens. ② Video output terminal Sends video signals and connects to the video input terminal of the monitor. ③ Power lamp Lights up when the correct power is supplied to the camera. ④...
-
Page 9: Installation
4. Installation 1) Lens Lenses are sold separately. Lenses such as auto iris lens, CS-Mount lens and C-Mount lens can be used. Note) • Use of the DC auto iris lens is recommended to achieve the best results for operating this product effectively. - Page 10 LENS Pin No. VIDEO No.1 Pin Damping- Red(power) No.2 Pin Damping+ No.3 Pin Drive+ White(video signal) No.4 Pin Drive- Black(GND) Please replace the auto iris lens connection plug cover and take off the lens protection cap, and then attach the auto iris lens to the camera by screwing it in clockwise.
- Page 11 Caution Make sure that user can’t use video type lens using high voltage camera. ② When using a CS-Mount lens Please take off the lens protection cap and attach the CS-Mount lens to the camera by screwing it in clockwise. ③...
- Page 12 Note) • Please use the specified lens connection parts as shown in the picture below. The use of the wrong sized parts may cause damage to the inside of the camera or result in poor fitting. • Use of a lens which is too heavy affects the balance of the camera and may cause a malfunction.
-
Page 13: Setup Menu Operation
5. Setup Menu Operation •Please press the SETUP button to set OSD menu. The SETUP menu is displayed like under the picture on the monitor. SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY& NIGHT COLOR SPECIAL RESET EXIT • if it has been selected. You may move up/down to use another function by up/down buttons and change the status by pressing left/right buttons. - Page 14 When the SETUP menu screen is displayed, select EXPOSURE by using the Up and Down buttons so that the indicates EXPOSURE. Select a desired mode using the UP and DOWN buttons. ① SHUTTER You can select either auto or manual shutter. •...
-
Page 15: White Balance
WHITE BALANCE SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY& NIGHT COLOR SPECIAL RESET EXIT The screen color can be adjusted by using the WHITE BALANCE function. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. ①ATW1: This automatically finds white color from color temperature between 2000~18,000°K. - Page 16 BACKLIGHT When there is a strong backlight behind the object, clear images of the background as well as the object can still be obtained by using the BLC or HLC function. SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY& NIGHT COLOR SPECIAL RESET EXIT...
- Page 17 DAY & NIGHT SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY &NIGHT COLOR SPECIAL RESET EXIT You can display pictures in color or black and white. When the SETUP menu screen is displayed, select ‘DAY/NIGHT’ by using the UP and DOWN buttons so that the arrow indicates “DAY NIGHT”. Please select the mode you wish to operate by pressing the LEFT or RIGHT button.
- Page 18 ③ B/W : This mode allows you to apply B/W mode. BURST IR SMART IR LEVEL RETURN • burst: If it cannot be synchronizing video on the monitor in the BW mode of camera, it turns on. (When the camera in B/W mode, the WHITE BALANCE is deactivated.) If DAY NIGHT mode is AUTO, the AGC is fixed HIGH.
- Page 19 SPECIAL Select ‘FUNCTION’ key from SETUP menu and press Set key to change ‘FUNCTION’ setup. SETUP LENS SPECIAL EXPOSURE CAM TITLE WHITE BAL MOTION BACKLIGHT PRIVACY DAY& NIGHT COLOR PARK LINE IMAGE ADJ. ↙ VERSION SPECIAL RETURN RESET EXIT ①CAM TITLE SETUP CAM TITLE MOTION...
- Page 20 • If you press the SETUP button after moving the cursor to CLR, all the letters will be erased. If you want to correct a letter, please move the cursor to the arrow at the bottom left of the screen and press 'SET'. •...
- Page 21 MOTION SPECIAL AREA SLE AREA1 CAM TITLE AREA STATE MOTION HEIGHT -------|------04 PRIVACY WIDTH -------|------04 PARK LINE LEFT/LIGHT -------|------02 IMAGE ADJ. ↙ TOP/BOTTOM -------|------02 VERSION DEGREE -------|------35 RETURN VIEW RETURN ▶ ON: If ‘MOTION’ function is active, character of person is flickering on right above position when motion is detected on selected area.
- Page 22 • AREA SELECT: Select the programmed privacy area (No.1~8) • AREA STATE: Turn on and off the programmed privacy masking. • HEIGHT: Adjust vertical height of the programmed privacy area. • WIDTH: Adjust horizontal width of the programmed privacy area. •...
- Page 23 Adjust this value appropriately depending on the sharpness of the picture. Level : 1 ~ 016 • - DISPLAY User can select kind of the monitor that user want to use. CRT / LCD / MANUAL • If you select kind of the monitor, you can put setting value like PED level and color gain - NEG.
-
Page 24: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Problems Troubleshooting Nothing appears on the screen. • Please check the power connection. • Please check the video signal line connection. The video image is not clear. -
Page 25: Specifications
7. Specifications SIGNAL SYSTEM NTSC IMAGE SENSOR 1/3" Super Sony HAD CCD TOTAL Pixels 811(H) × 508(V) 795(H) × 596(V) Effective Pixels 768(H) × 494(V) 752(H) × 582(V) RESOLUTION More than 650 TV lines Scanning Frequency 15.734KHz(H), 60(V) 15.625KHz(H), 50(V) Shutter Speed 1/60~1/100,000 sec 1/50~1/100,000 sec...
