Summary of Contents for D-MAX Pixim Seawolf DSP
- Page 1 Super Wide Dynamic Range Dome Color Camera 사용 설명서 MANUAL 용 서 Pixim Seawolf DSP...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not install the camera on a surface that can not support it.
- Page 4 1. Features Our WDR camera is a superb wide dynamic range camera which achieves 120dB max(102dB typical) of dynamic range of the image by implementing PIXIM's Seawolf digital imaging system. With Seawolf digital imaging system, - Delivers high-resolution, crystal clear images that accurately capture every aspect of any scene - Offers the highest resolution of 690TVL(horizontal) - Ultra-wide dynamic range imaging accurately captures all of the critical details in a...
-
Page 5: Cable Connection And Osd Control
2. Cable Connection and OSD Control 1) Cable Connection 2) OSD Control ② SETUP button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. ③... -
Page 6: Setup Menu Operation
3. Setup Menu Operation 1) In the menu Use ▲, ▼ buttons to move menu, ◀, ▶ buttons to change the settings and press button shortly to select or enter. button stands for MENU or ENTER button. 2) Entering menu Press button longer than 2 sec on the back of camera. - Page 7 4) EXPOSURE To enter EXPOSURE menu, press button at MAIN>EXPOSURE. EXPOSURE Default Descriptions EXPOSURE Descriptions In NTSC system, the entire color tone on the monitor may continuously <WDR MID> Medium level of the dynamic range control for each PRESETs. move reddish and greenish. WDR HIGH Increases the dynamic range control.
- Page 8 5) DAY/NIGHT To enter EXPOSURE menu, press button at MAIN>DAY/NIGHT>AUTO... IMPORTANT!!! IMPORTANT!!! DAY->NIGHT and NIGHT->DAY operations must be examined and verified at the final step of the installation. Block the lens for a few seconds for NIGHT mode and release and let it return to DAY mode. If camera stays at NIGHT mode more than 10sec, increase N-->D THRES a little and repeat the fore-mentioned steps.
- Page 9 6) 3D NR To enter EXPOSURE menu, press button at MAIN>3D NR 3D NR Default Descriptions Determines the depth of Three Dimensional Noise Reduction. DEPTH High value reduces the noise strongly but the comet effect may occur for the fast moving object and vice versa. 7) LENS SELECT To enter EXPOSURE menu, press button at MAIN>LENS SELECT>DC...
- Page 10 PICTURE Factory PICTURE Factory Descriptions Descriptions CONTROL Default PICTURE Factory CONTROL Default Descriptions Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL. CONTROL Default Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL. ATW NORMAL – Compensates automatically in range of 2800K-7500K. Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL.
- Page 11 ① MOTION Up to 4 motion areas and the sensitivity can be set. The sensitivity is applied for all zones equally. In adjusting each zone, the zone border line changes color when pressing button. Green enables enlarging, red enables reducing and white enables moving the zone by ▼, ▲, ▲, ▼buttons. To exit MOTION ZONE SETUP, press button for 2 seconds.
- Page 12 button at ,ON..>, the button, the Right after pressing Right after one more pressing 1st zone appears on top-left corner in orange. 1st zone changes to blue. Blue colored zone can be resized with . ▼, ▲, The orange colored zone can be relocated in its location with ▼, ▲, ▲, ▼...
-
Page 13: Save And Exit
D-EFFECT Default Descriptions FREEZE Image freezes and shows the still image at the moment when set to ON.. OFF(Normal display), H-FLIP(left & right flipped), V-FLIP(upside down FLIP flipped), H/V-FLIP(left & right flipped and upside down flipped.) Direction of joystick control should be flipped if V-flip is flipped to H/V-flip. D-PTZ Able to set digital zoom up to x12 and digital PAN/TILT if zoom ratio >1. -
Page 14: Troubleshooting
If there are problems in operation, please refer to the items below. If the problem persists, Troubleshooting please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •... - Page 15 5. Dimensions...
-
Page 16: Specifications
6. Specifications ▪ GENERAL Model name NTSC Image Device 1/3" CMY Color DPS SENSOR (Pixim Seawolf D8800C series) Effective Pixels 768(H) x 540(V) TV system NTSC, 525lines / 2:1interlace PAL, 625lines / 2:1interlace Scan frequency. 59.94Hz(V), 15.734Khz(H) 50Hz(V), 15.625Khz(H) Synchronization Internal/Line lock (Default: Internal) H. - Page 17 ▪ DOME CASE Dome Type Install Type Indoor Outdoor(IP66) Outdoor(IP66) 100(Bubble) x 139.5(H) 100(Bubble) x 103(H) 100(Bubble)x 107.5(H) Dimension(mm) 3 Axis 3 Axis 3 Axis 3 Axis Material Plastic Body, PC Bubble, PC Bubble, PC Bubble Aluminum Body Aluminum Body Weight 560g 1.1Kg...
