  • Page 1 2Megapixel Hybrid TVI & AHD Mini Speed Dome Camera User manual Version. 100927...
  • Page 2 AHD and TVI video output selection Indoor Outdoor Set AHD or TVI video output using dip Loosen the four bolts of the Bubble Cover, switches on the camera body at bottom Remove the camera housing, and set AHD or TVI cover.

  • Page 3: Table Of Contents

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual Content Caution........................................4 Product Introduction ..................................6 Description and features ............................6 2.1. Product package ................................7 2.2. Name and function of each part ..........................8 2.3. Installation ..................................10 2.4.

  • Page 4: Caution

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 1. Caution Thank you for purchasing our product. Please operate the product after being fully aware of the manual. Pease contact us if you have any query. Precaution Note the following matters before the installation of the product. Avoid the following places for the installation.
  • Page 5 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual This product has been designed and manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives. Electromagnetic Compatibility Directive 89/336/EEC(EN61000-3-2:1995, EN61000-3-3:1995, EN50081- 1:1992, EN50082-1:1997) This devise complies with part 15 of the fcc rules operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received including interference that may cause undesired operation...

  • Page 6: Product Introduction

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2. Product Introduction 2.1. Description and features This camera, 2 Megapixel speed dome camera, has been designed Full HD TVI/AHD Hybrid Mini elegantly for buildings, department stores that need to be in harmony with the interior as a high speed dome camera, including various observation functions.

  • Page 7: Product Package

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.2. Product package The following items are included in the product package. Item Q`ty Outdoor type Indoor type MEGA Speed Dome 1 pcs Camera Wall Mount Bracket 1 pcs Power Supply (Power Cable &...

  • Page 8: Name And Function Of Each Part

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.3. Name and function of each part - Exterior - Name Function ① Dome Clear Bubble Protect Lens and PTZ dome drive ② PTZ Camera PTZ dome drive (Pan/Tilt/Zoom) ③...
  • Page 9 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual - Interior - Connect Cover ④ ③ ① ② ⑥ ⑤ Name Function ① Power Port AC 24V / 2A Power input ② RS-485 Communication Port RS-485 PTZ control communication port ③...

  • Page 10: Installation

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.4. Installation 2.4.1. Installing wall mount bracket-(Outdoor) ① Loosen the 4 bolts of Bubble Cover disconnect camera housing. ③ Connect the power, data, & video cables to the connection part of Connect Cover and then set the DIP SWITCH.

  • Page 11: Basic Installation For Indoor

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.4.2. Basic Installation for Indoor ① Make 4 holes after ② Take out the cables from the ③ Take apart 4 bands of camera body cover. attaching ceiling guide ceiling.

  • Page 12: Wall Bracket Installation For Indoor Type

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.4.3. Wall Bracket Installation for Indoor Type It can be connected with bracket by using mount. (The mount and bracket are optional item for indoor type. ) ① ② Fix 4 screws. ③...

  • Page 13: Installing Ceiling Mount Bracket -Outdoor

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.4.4. Installing Ceiling Mount Bracket -Outdoor ① Loosen the 4 bolts of Bubble Cover disconnect camera housing. ② Attach Pole box on the ceiling. ③ Tighten Ceiling pole to pole box ④...

  • Page 14: Using Speed Dome Junction Box

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 2.4.5. Using Speed Dome Junction Box - Speed dome junction box installation - Fasten screw up 4 screws of the junction box in order of Camera housing → Wall mount bracket → Water-proof cover →...
  • Page 15 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual AC 24V Power Supply AC 24V Input Port AC 24V Output Port Power LED LAN (output) LAN (Input) Output port Input port AC IN AC OUT ※ Please refer to the speed dome junction box user manual.

  • Page 16: Installing Corner Mount

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual Installing Corner Mount 2.4.6. When installing the wall mount bracket to the corner of wall, install it with the corner mount. 2.4.7. Installing Pole Mount When installing the wall mount bracket on the cylinder, combine it with the pole mount and install it.

  • Page 17: Dip Switch Setting

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3. DIP switch setting Switch 3.1. DIP setting <S1>  SET No#1~7 DIP SWITCHES FOR CAMERA ADDRESS.  SET INIT SWITCHES CAMERA PROTOCOL & BAUD RATES. (This part is each address of camera) ...

  • Page 18: Protocol Setting

    Set up the switch. (8th DIP SIWTCH can converted NTSC/ PAL SIGNAL.) The switch for select protocol The switch for select baud rates PROTOCOL SW 'INIT←→ADDR' D-MAX (9600 bps) INIT P-P (9600 bps) INIT P-P (4800 bps) INIT P-P (2400 bps)

  • Page 19: Address Dip Switch Setting

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual Address DIP 3.3. Switch Setting ADDRESS is set No 1~128 by DIP switch 1~7. DIP SWITCH (HEX) DIP SWITCH (HEX) - ADDRESS Table - - 7 DIP switched on, it can be set 65 ~ 128 as above.

  • Page 20: Osd Menu Setting

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3.4. OSD Menu setting 3.4.1. OSD Menu control ■ OSD (ON SCREEN DISPLAY) menu control It is the function to call up the Menu of the camera. ◈ User can not only set Preset, Group, Tour, Swing, Trace functions of the camera up by the menu, but also set them up by shortening keys.

  • Page 21: Menu Function

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3.4.2. Menu function ■ OSD Menu tree Main menu Sub menu 1 Sub menu 2 SELECT PRESET PRESET ID SET PRESET PTZ SET SWING SET SET PTZ FUNCTION GROUP SET CH:01~12 TOUR SET TRACE SET DOME DRIVER SET...
  • Page 22 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual - DOME DRIVER SET. : Set Pan, Tilt or various surveillance functions. - CAMERA SET. : Set Video, screen display functions. - SPECIAL SET. : Set motion detection, alarm, multi-language, Password, Factory default - TIME SCHEDULE SET.
  • Page 23 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual User can select ID letter or icon by using joystick Up/Down/Right/Left. Shift letter digit by "ZOOM PRESET CH:001[PRESET:001] ! " $ % & ' ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ;...
  • Page 24 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual - SET PRESET & RUN. - SWING SET. 1. SELECT PRESET CH:001 2. PRESET ID SET 1. PAN/TILT SWING : UNDEF 3. PRESET PTZ SET : 000 2. START PRESET 4.
  • Page 25 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual Move next menu Move previous menu Change setting 6). TOUR SET Tour is included 12 groups. - SET PRESET & RUN. 1. SELECT PRESET CH:001 2. PRESET ID SET - TOUR SET.
  • Page 26 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ TRACE Set ① "7. TOUR SET" ② Press F/N button to select “SET” mode → move camera by using joystick toward position you want up to for 180/sec ③...
  • Page 27 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ Setting - DOME DRIVE SET → SET PRIVACY → Enter PRIVACY ZONE SET Mode Move Joystick up / down at desired channel then display black box In the middle of screen by pressing “F/F”...
  • Page 28 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ CAMERA SET 1. ID SET It is set camera ID up to 16 English letters it is enable to << DOME CAMERA SETUP >> select desired letter by joystick zoom and save camera ID - DOME DRIVER SET.
  • Page 29 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 4. SHUTTER SPEED Adjust camera electronic Shutter speed. - CAMERA SET. Factory default: Auto. 1. ID SET(PRESS F/F KEY). ▶ Range : A.FLICKER, AUTO, 1/50,60~1/30000 : NORMAL 2. H-V REVERSE 3.
  • Page 30 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 10. DNR LEVEL Reduce noise of minimum illumination and also file - CAMERA SET. size becomes smaller while DVR is being recorded by 10. DNR LEVEL : AUTO the effective reduction of noise. 11.
  • Page 31 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual - WDR SET. WDR SET 1. WDR LEVEL : MIDDLE - WDR LEVEL: Set WDR sensitivity, Low or Middle or Max. . RETURN TO MENU. - HLC SET. HLC (High Light Compensation) SET 1.
  • Page 32 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 15. WHITE BALANCE The white balance menus adjusts the balance of the screen colors under differnet lighting condition. ▶ AUTO: Compensates the color automatically. ▶ INDOOR: Compensates the color to fit the indoor environment. ▶...
  • Page 33 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ SPECIAL SET 1. OSD DISPLAY - SPECIAL SET. << DOME CAMERA SETUP >> - DOME DRIVER SET. 1. OSD DISPLAY : ID+STATUS : SENSOR - CAMERA SET. 2. SELECT ALARM 3.
  • Page 34 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ Set up motion detection ① "2. SELECT ALARM". Select “motion”. ② "3. MOTION DETECTION" select "ON" Change to screen for motion detection area set mode by pressing F/F key. ③...
  • Page 35 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual - It is checked exist Alarm status in the keyboard, if it is sensed wrong signal, the keyboard makes beep - SPECIAL SET. - ALARM PRESET SET. 1. OSD DISPLAY : ID+STATUS CH 01: CH 02:...
  • Page 36 Dehumidification again, you could select the function in the OSD. . ▶Turn ON : 1 + AUX1 + ON OFF : 1 + AUX1 + OFF It is available to set Dehumidification under D-max protocol by D-max brand keyboard; it is displayed icon on the screen. 11. LANGUAGE - Multi-language ▶...
  • Page 37 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 13. CHANGE PASSWORD - "13. CHANGE PASSWORD" the user can select password by Joystick Left / Right. - SPECIAL SET. 9. USE SHORTCUT KEY : ON - CHANGE PASSWORD. 10.
  • Page 38 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ■ TIME SCHEDULE SET 1. SCHEDULE FUNCTION SET - TIME SCHEDULE SET. << DOME CAMERA SETUP >> - DOME DRIVER SET. 1. SCHEDULE FUNCTION SET. - CAMERA SET. 2. SCHEDULE BACKLIGHT SET. 3.
  • Page 39 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual then set the operating start time and the stop time for DEFOG in [START~END]. 5. Setting DEHUMIDITY(=DEHUMIDIFICATION) SCHEDULE: When the operating start time is set with DEHUMIDITY function 'ON', the fan & heater will work for 10 minutes on time. ※...
  • Page 40 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3. RESUME TIME SET - TIME SCHEDULE SET. It can select the delay time that the camera move to 1. SCHEDULE FUNCTION SET. the place alarming to observe where wrong signal is 2.
  • Page 41 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 5. TIME SET This function can set the operating time and the time compensation. - TIME SCHEDULE SET. - TIME SET. 1. SCHEDULE FUNCTION SET. 1.CHANGE TIME : 00/00/00 2.

  • Page 42: Set-Up Menu, Execute And Delete By Keyboard

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3.4.3. Set-up menu, Execute and delete by keyboard 1. Preset Setting Save Max. 250 Preset points ① Preset set up ② Preset movement Move designated preset position after press Preset No and P-SET button.
  • Page 43 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3. Group setting ① Start Group setting mode To set more preset, enter preset No and set same process. Set a GROUP again from the first after ending with , if user wants to finish Preset input in one Group to input another Group.
  • Page 44 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual ② Tour execute/Stop ③ Tour remove (Holding 3 seconds ~) 5. Spiral Function It is a function to observe objects automatically in the spiral direction. ② Spiral Off Spiral On * 26.

  • Page 45: Osd Message Description

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 3.4.4. OSD Message Description 1. PRESET Message CAM-001 CAM-001 CAM-001 SAVE PRESET:001 PRESET:001 CLEAR PRESET:001 It appears when user deletes It appears when moving to the User can check that Preset PRESET No.1.
  • Page 46 2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 4. TOUR Message CAM-001 CAM-001 CAM-001 Set Tour GP:01 [TOUR&GP:01] PRESET:001 CLEAR TOUR&GROUP. As the message in the time of As the message in the time of It shows the data in GROUP and operation of Tour set, “GP:01”...

  • Page 47: Trouble Shooting

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 4. TROUBLE SHOOTING CAUTION IN USE • Make sure that turn the power switch off before installation. • Avoid the places where is the high/low temperature and humid. • Power supply must be min AC24V/2A. •...

  • Page 48: Dimension

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 5. Dimension 5.1. Outdoor type ■ Installing wall mount bracket ■ Installing Ceiling Mount Bracket Unit : mm...

  • Page 49: Indoor Type

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 5.2. Indoor type Unit : mm...

  • Page 50: Configuration Diagram

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 6. Configuration diagram • CAMERA + DVR + MONITOR (Control camera OSD by DVR) • Camera + DVR + Monitor + Controller...

  • Page 51: Specification

    2Mega TVI & AHD Hybrid Mini Speed Dome Camera User manual 7. Specification TVI & AHD Hybrid Mini Speed Dome Camera MODEL Outdoor Indoor Video 1/3” 2Mega Panasonic CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 1,956(H) x 1,266(V), 2.4M Pixels Number of active pixels 1,944(H) x 1,213(V), 2.3M Pixels Resolution...
