- Page 1 2Mega Pixel HD-SDI Camera USER MANUAL Full HD (1080P) EX-SDI/HD-SDI...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Contents 1.Features --------------------------------- 2. Menu Construction --------------------------------- 3. Dimensions & OSD board configurations --------------------------------- 4. Specifications ---------------------------------...
-
Page 4: Features
Features ■ 1/3" 2MEGA SONY CMOS High definition 12-bit digital image signals offering 2 mega pixels are obtained with high speed of 30 fps and with low power consumption. ■ High Resolution 1100(Color)/(BW) TV Lines This camera has realized high resolution of 1100(Color)/(BW) TV lines using the top-notch full digital image processing, 12 Bit A/D serial signal processing and special algorithm technologies. -
Page 5: Menu Construction
Menu construction All functions would be set by OSD menu. The menu consists of the main menu and sub menu. Sub menu is displayed when user press set key on each menu, at which you see arrow. Please hold the “SET” key for a while to enter OSD menu. - Page 6 frequency and the blinking frequency of the lighting. 3) TCS INFO This function can capture clear image when the object move fast. OPTION DESCRIPTION - TCS MODE NOT USED Select TCS level MODE1~5 Shutter 1/120~6000 + DN EXT + Smart IR 14 MODE6~10 Shutter 1/120~1600+ User DN + User Smart IR MODE11~15...
- Page 7 2) HLC High Light Compensation ▶ON(0~20), OFF LEVEL: Select HLC level. COLOR: Select HLC color(CYN, YEL, WHT, BLK, BLU, RED, MAG, GRN) 3) WDR Wide Dynamic Range WEIGHT:LOW/MIDDL/HIGH 5. DAY/NIGHT The function is used to set the Day/Night function which switches day/Night mode automatically based on the level of illumination.
- Page 8 3) AUTO ext: TDN lens Auto trace white balance. It can be changed in AWC mode only. 4) Preset: when the set color temperature doesn’t meet with user’s environment. 7. DNR Set up 3D-DNR (Digital Noise Reduction) level. ▶OFF, LOW, MIDDLE, HIGH 8.
- Page 9 -In case of box type ZONE NO (0~15): Select 16 areas using left or right button. ZONE DISP (ON/OFF): Show up PRIVACY AREA function on the screen. H-POS (0~60): H position. V-POS (0~34): V position. H-SIZE (0~40): H size. V-SIZE (0~34): V size. Y LEVEL(0~20): Adjust the Y LEVEL of the Privacy zone area CR LEVEL(0~20): Adjust the B GAIN of the Privacy zone area...
- Page 10 DET V-SIZE(0~34): V size 10. OPTION Set camera ID and BAUDRATE for remote control. This camera supports D-max and Pelco protocol. In case of box camera can be used this function only. IMAGE RANGE (Full, Comp, User) Digital output data scale...
- Page 11 Please be advised that following guidelines before you go with POC You should use the POC device our D-MAX team offer Make sure to use power voltage in accordance with more than 19V 1A Non-IR camera gets its power supply from POC device up to 300m IR camera’s maximum transmission distance depends on the number of LED.
-
Page 12: Dimensions & Osd Board Configurations
Dimensions & OSD Board Configuration 1. BOX CAMERA... - Page 13 2. DOME CAMERA Dimensions OSD Board 3. VANDAL DOME CAMERA Dimensions OSD Board...
- Page 14 4. IR DOME CAMERA (24IR) Dimensions OSD Board 5. IR VANDAL DOME CAMERA (30IR) Dimensions OSD Board...
- Page 15 6. IR BULLET CAMERA (36IR) Dimensions OSD Board 7. IR BULLET CAMERA (54IR) Dimensions OSD Board...
-
Page 16: Specifications
Specifications 1. BOX CAMERA MODEL Box Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M S/N Ratio... - Page 17 2. DOME CAMERA MODEL Dome Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M S/N Ratio...
- Page 18 3. VANDAL DOME CAMERA MODEL Vandal Dome Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M S/N Ratio...
- Page 19 4. IR DOME CAMERA (24IR) MODEL IR Dome Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M...
- Page 20 5. IR VANDAL DOME CAMERA (30IR) MODEL IR Vandal Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M...
- Page 21 6. IR Bullet CAMERAIR (36IR) MODEL IR Bullet Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M...
- Page 22 7. IR BULLET CAMERA (54IR) MODEL IR Bullet Type Video 1/2.8” 2.4Mega(1080p) PS-Sony CMOS Image Sensor Scan mode Progressive Scan Total number of pixels 2000(H) × 1241(V) Number of active pixels 1984(H) x 1097 (V) Resolution 1,100 TVL Minimum illumination 0.001Lux with Sense-up(32x) Video Output HD-SDI/EX-SDI, SMPTE-292M...
- Page 24 DISTRIBUTED BY...
