Summary of Contents for D-MAX DCC-700d Series
- Page 1 High Resolution / Day & Night COLOR DOME TYPE CAMERA MANUAL 680 TVL 960H, UTC, Defog...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
- Page 4 ■ Precautions Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting change or flicker can It is one of the most important parts of cause the camera to work improperly.
-
Page 5: Table Of Contents
■ Contents --------------------------------- 6 1.Features --------------------------------- 7 2. Cable Connection & OSD Control --------------------------------- 8 3. Setup Menu Operation --------------------------------- 18 4. Troubleshooting --------------------------------- 19 5. Dimensions --------------------------------- 22 6. Specifications... -
Page 6: Features
1. Features ■ 1/3" 520K/610K Sony Super-HAD CCD II Minimum Low Illumination (F1.2, 50 IRE) ■ High Resolution 680 TV Lines This camera has realized high resolution of 680 TV lines using the top-notch full digital image processing, 10 Bit A/D serial signal processing and special algorithm technologies. ■... -
Page 7: Cable Connection & Osd Control
2. Cable Connection & OSD Control 1) Cable Connection 2) OSD Control ① 3AXIS BRACKET - Please loosen screws and fix tilted and panned position. ③ LENS : Vari-Focal Auto Iris Lens ③ OSD PCB SETUP button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. -
Page 8: Setup Menu Operation
3. Setup Menu Operation ◆ Menu configuration CAMERA TITLE CAM ID ID DISP CAMERA SET FONT COLOR COMMUNICATION LANGUAGE VERSION LENS BRIGHTNESS SHUTTER EXPOSURE AUTO NIGHT DAY/NIGHT EXT. WHITE BAL. MANUAL PUSH GAMMA CHROMA SHARPNESS MONITOR SHADING PED. LV. BLACKLIGHT CONTRAST POSI/NEGA IMAGE... - Page 9 ■ CAM TITLE Make a set camera title using below numbers and alphabets (0,1,2,3,4,5,6,7,8,9,A,B,C,D,E,F,G,H,I,J,K,L, M,N,O,P,Q,R,S,T,U,V,W,X,Y, Z) ◇OFF: disable CAMERA TITLE. ◇ON: display CAMERA TITLE. ■ CAM ID You can set CAMERA number from 1 to 255. ■ ID DISP ◇OFF: disable CAMERA NO/ID. ◇ON: display CAMERA NO/ID ■...
- Page 10 ◇ BRIGHTNESS(1~20) The BRIGHTNESS menu is used to adjust the overall brightness, where "▶" will increase the brightness and "◀" will decrease it. ◇ SHUTTER The SHUTTER menu is used to set the fixed high-speed electronic shutter, auto high speed electronic shutter. You can select one of 13 options from 1/100( PAL:1/120 ) for the fixed high speed electronic shutter, which is mostly used for imaging a fast moving object.
- Page 11 ◆ DAY/NIGHT(AUTO, DAY, NIGHT, EXT) ■ AUTO The camera will automatically switch between DAY and NIGHT mode, according to the lighting condition. If you press the ⓔ( Enter ) switch with an AUTO based sub menu selected, you will see the appropriate screen. ◇...
- Page 12 ■EXT. This enables to switch between DAY and NIGHT mode using the interface with external signal. ◆ WHITE BAL.(White Balance) Use the White Balance function to adjust the screen color. ◇ ATW The camera can automatically adjust the color temperature in real time, according to the ambient conditions.
- Page 13 ◇ PUSH If you press the ⓔ( Enter ) switch in the appropriate item position, Auto White Balance will perform once. ◇ MANUAL In this mode, you can set the color temperature of RED and BLUE. ◆ MONITOR Please change the settings value of video appropriate to your monitor. ◇...
-
Page 14: Back Light
◇ CHROMA: Color Gain Set ◇ SHARPNESS: Aperture (Horizontal,Vertical) Set ◇ SHADING: Lens Shading ◇ PED. LV.:Pedestal Level Set ◆ IMAGE ■ BACK LIGHT ◇ BLC Adjusts the area to be enhanced and sets the level. ◇ HLC If the scene contains extremely bright light areas such as; from car headlight, the light can mask out much of the on-screen detail. - LEVEL: Adjusts the brightness level of a monitoring area. - Page 15 ■ CONTRAST ◇ D-WDR When there are both bright and dark areas at the same time, this mode makes both areas distinctive. ◇ DEFOG This camera supports DEFOG function which does a process of clearing blurred image caused by fog and snow by analyzing the brightness of input image and compensating the color of the image ◇...
- Page 16 ■ H - MIRROR ◇ H – MIRROR You can flip the picture - MIRROR: Horizontal reverse pictures on the monitor. ◇ PRIVACY You may conceal specific area on the screen with this ‘PRIVACY’ function. You can set masking areas up to 8 zones. ◆...
- Page 17 ◇ SENSITIVITY Set the sensitivity of the motion detection from 0(Highest) to 15(Lowest). ◇ AREA NO Specify a detection area. You can set the area from 1 to 4. ◇ AREA USE With the DISPLAY option set to ON, a motion function will be displayed on the screen, if detected.
-
Page 18: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •... -
Page 19: Dimensions
5. Dimensions DOME CAMERA... - Page 20 VANDAL DOME CAMERA...
- Page 21 IR DOME CAMERA IR VANDAL DOME CAMERA...
-
Page 22: Specifications
6. Specifications ▪ GENERAL Signal system NTSC 1/3” 960H Super HAD Sony CCD∥ Image Sensor Total Pixels 1028(H)X508(V) 1028(H)X596(V) Effective Pixels 976(H)X494(V) 976(H)X582(V) Resolution 680 TV lines (B/W 750 TV Lines with ICR) Scanning Frequency 15.734KHz(H), 60Hz(V) 15.625KHz(H), 50Hz(V) Min. Illumination 0.08Lux(50IRE) Day &... - Page 23 Dome type Number Install Type Indoor Indoor Indoor Indoor 100x76.5(H) 120x95(H) 100x103(H) 81x87(H) Dimension(mm) 3 Axis 2 Axis 2 Axis 3Axis 3Axis Material Plastic Body & Plastic Body & PC Bubble & PC Bubble & Bubble Bubble Plastic Body Plastic Body Weight 300g 560g...
