02 Connecting up
2 Connect the analog AUDIO OUT L/R
and VIDEO OUT jacks on this player to a
set of analog audio and video inputs on
your AV receiver.
AV receiver
Y
IGITAL
COAXIAL
UDIO OUT
S
OPTICAL
VIDEO OUT
The diagram shows standard video
connections, but you can alternatively use the
SCART-type AV, S-video or component video
connections if they're available.
3 Connect the AV receiver's video
output to a video input on your TV.
• You usually have to connect the same
kind of video cable between your DVD
player and AV receiver, and between your
AV receiver and TV.
18
En
AUDIO/
VIDEO IN
AUDIO OUT(2CH)
P
B L CENTER
L
AUDIO OUT(5.1CH)
R
R
P
R FRONT SURROND SUB
WOOFER
COMPONENT VIDEO OUT
Controlling this player from
another Pioneer component
This player has SR jacks which allow you to
use the remote sensor on one Pioneer
component to control another.
Use a mini-jack plug to connect the
CONTROL OUT of one component to the
CONTROL IN of another. In this way you can
daisy-chain several components together.
CONTROL
OUT
CONTROL
IN OUT
R 2 AV CONNECTOR 1(RGB) - TV/AV Receiver
CONTROL
IN
• My TV doesn't have any inputs to connect
the DVD player. How can I watch DVDs?
If your TV has no inputs you can't use this
player with it.
• My VCR is already connected to my TV, so
there aren't any spare inputs. What should
I do?
If all your TV's inputs are already in use,
you can buy a video input selector from an
electronics store, which effectively gives
you more inputs.
Pioneer AV receiver
Y P
B
DIGITAL COAXIAL
AUDIO OUT
S P
OPTICAL R
VIDEO OUT
COMPON
Pioneer CD player, etc.
