- Page 1 ProClubLine FLYING PULL UP MODEL # SR-FPU & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L V.
- Page 2 DO NOT allow children or minors to play on or around this equipment. If unsure of proper use of equipment, call your local Body-Solid distributor or the Body-Solid customer service center at (800) 556-3113.
- Page 3 T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • ASSEMBLY INSTRUCTIONS......PAGE 6 • CONTACT PAGE..........PAGE 10...
-
Page 4: Obtaining Service
When using exercise equipment, you The SR-FPU is designed for your enjoyment. By should always take basic precautions, following these precautions and using common sense, including the following: you will have many safe and pleasurable hours of healthful exercise with your Pro Club Line by m Read all instructions before using the SR-FPU. Body-Solid, FLYING PULL UP These instructions are written to ensure your safety and to protect the unit. After assembly, you should check all functions to ensure correct operation. If you experience problems, m Do not remove any safety labels from the first recheck the assembly instructions to locate any machine. -
Page 5: Assembly Tips
P r e p a r a t i o n Thank you for purchasing the SR-FPU. This Rig is part of Pro Club Line by Body-Solid of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the SR-FPU include but are not limited to: step. While you may be able to assemble the SR-FPU m Metric Wrench Set using the illustrations only, important safety notes and other tips are included in the text. m Adjustable Wrench m Bolts and Nuts require 30mm Wrenches Some pieces may have extra holes that you will not use. Use only those holes indicated in the instructions and illustrations. Installation Requirements NOTE: With so many assembled parts, proper alignment and adjustment is critical. While Follow these installation requirements when assembling... - Page 6 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 1. Nylon lock nuts will not fully screw onto bolts, they must be wrench tightened to fully go on. Attach one Pull Up Bar with Rings (9) and four Pull Up Bar (10) to the Frames (11 &12) using: 10 - (#6) M10x90mm Hex Head Bolt...
- Page 7 S T E P Above shows Step 1 assembled and completed.
- Page 8 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 2. Nylon lock nuts will not fully screw onto bolts, they must be wrench tightened to fully go on. Attach Frames (11 &12) of the Flying Pull Up to the Uprights of the Rig using: 4 - (#1) M20x185mm Hex Head Bolt...
- Page 9 S T E P Above shows Step 1 assembled and completed.
- Page 10 Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs. All rights reserved on all design patents and utility patents.
