Glider Model Function Descriptions
your sailplane. If you have a nearby slope, practice flying
on very light lift days, where you can just barely keep the
model airborne. It is under these conditions that you
learn whether your model is really trimmed properly.
MX.SS Mix Switch Select
Current Mixing switches can be assigned to new other
switches for user convenience.
to be exactly the same as like right diagram, (all switches must
be positioning on normal )
2. Pressing the Cursor Right to change the assign new Mix
Switch for your convenience .(refer to page 37- Default)
Current mixing switch will be showing by flashing channel
numeral and highlighted On or Off sign.
Flashing
4. To go to next switch assigning, current new assigned switch
have to be OFF. Current assigned switch is On, cannot move
next switch to assign.
Ex) After assigned PMX 1 switch, and then press Cursor Right
in order to move PMX 2 . at this time , PMX 1 Switch has to be
OFF. If PMX 1 switch is ON , we cannot move next switches .
Flashing
if you want to assign this function to throttle stick, STICK sign
in the display have to be flashing(being select) . You can select
STICK sign through pressing the DATA + , DATA- key. If you
assigned this function to throttle stick , you cannot find SET
function in the CROW menu.
1.To set the MX.SS ,get to the
MX.SS screen with the Edit Up
Down keys (press at the same
time. and then search MX.SS
by pressing Edit Up or Down
repeatedly ). In the display has
3. You can be assigned new
mixing channel by pressing
Data +Increase, -Decrease keys
or toggle switch . also you can
check the new assigned switch
which being set (by numeral
flashing ) or On or Off status..
5. Pressing the Cursor Right to
find THRO function. This is only
can use in Glider type. Current
3CH function (Motor On/Off or
Spoiler) can be assigned by
throttle Stick or other switches .
