D-MAX DWC-540DV Manual

Super wide dynamic range vandal dome color camera

Advertisement

Quick Links

Super Wide Dynamic Range
Vandal Dome Color Camera
MANUAL
DWC-540DV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWC-540DV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for D-MAX DWC-540DV

  • Page 1 Super Wide Dynamic Range Vandal Dome Color Camera MANUAL DWC-540DV...
  • Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not install the camera on a surface that can not support it. Unless the surface is suitable, it could cause falling or other hazards.
  • Page 4: Table Of Contents

    Contents 1.Features -------------------------------- 2. Components & Cable Connection --------------------------------- 6 3. Names and functions of parts --------------------------------- 7 4. Installation --------------------------------- 8 5. Setup Menu flow -------------------------------- 6. Setup page menu --------------------------------- 11 7. Special page 1 menu --------------------------------- 16 8.
  • Page 5: Features

    1. Features ☺ High resolution color for crisp, clear video ▪ Progressive image capture ▪ 540 HTVL equivalent ☺ High sensitivity for low-light images ▪ Advanced noise reduction technology ☺ Wide Dynamic Range provides excellent quality in high-contrast environments ▪ 120dB maximum dynamic range ☺...
  • Page 6: Components & Cable Connection

    2. Components and Cable Connection 1) Components 2) Cable Connection...
  • Page 7: Names And Functions Of Parts

    3. Names and Functions of Parts 1) Names and functions of parts Lens : Vari-Focal Auto Iris Lens ( 2.9mm ~10.0mm / F1.2 ) OSD PCB - Setup button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions.
  • Page 8: Installation

    4. Installation & Dimensions 1) Installation 2) Dimensions...
  • Page 9: Setup Menu Flow

    5. Menu Flow 1) Setup Page Menu SETUP PAGE LENS & VIDEO I/O SETUP LENS VIDEO MANUAL VIDEO NTSC RESOLUTION HIGH NORMAL AUTO HIGH CUSTOM WB CONTROL AUTO ATWDes SAVE AWC & ALL CHNGS MANUAL ADJ MODE KELVIN AUTO HIGH HIGHER HI’EST AUTO...
  • Page 10 2) Special Page 1 Menu SPECIAL PAGE 1 CAMERA ID CAMERA ID POSITION UP-DOWN UP-CENTER UP-RIGHT DOWN-LEFT DOWN-CENTER DOWN-RIGHT DAY&NIGHT AUTO SYNC MOTION DETECTION ZOOM PT BACKLIGHT AE PREFERENCE LIGHTS SHADOW SAVE & RETURN PAGE 2 3) Special Page 2 Menu SPECIAL PAGE 2 MIRROR FREEZE...
  • Page 11: Setup Page Menu

    6. SETUP PAGE MENU 1. LENS & VIDEO I/O SET Lens SETUP PAGE LENS & VIDEO I/O SETUP LENS DC Choose the lens type DC, Video and manual lens VIDEO MANUAL by using the selector button. VIDEO NTSC Video I/O RESOLUTION HIGH AUTO...
  • Page 12 4. WB CONTROL (White Balance Modes) White Balance is a function which compensates different colors of light being emitted from different light sources. Users can select the above levels as they desire according to the environment. SETUP PAGE AUTO (Auto Tracking White Balance) LENS &...
  • Page 13 6. DNR DNR is Digital Noise Reduction System with a maximum gain of 24 DB. SETUP PAGE By Setting it to AUTO Mode, Noise Will be Little LENS & VIDEO I/O SETUP RESOLUTION HIGH & OFF Mode Vice versa. AUTO WB CONTROL AUTO AUTO...
  • Page 14 WHITE BALANCE SPEED ATW Slew ATW slew controls the rate of change when transitioning from one color thmperature to another, An example of this would be panning the camera from an indoor fluorescent scene of 4000K out a window to a daylight scene of 6500K. The slew property tells the camera how fast to make the adjustment from 4000K to 6500K.
  • Page 15 fast or too small. If a change in meter reading is substantially enough to pass through these two blocks, the camera will respond. Then it’s a question of how quickly the camera will respond—which is the purpose of the next block. Trans The role of the transition block is to control the rate of the transition from old to new camera settings.
  • Page 16: Special Page 1 Menu

    7. SPECIAL PAGE 1 MENU 1. CAMERA ID User can enter a unique name for the respective camera. The maximum length of the ID is eight characters. You can choose the ON and OFF with the SPECIAL PAGE 1 selector.If you select ON, the entered camera ID CAMERA ID is displayed at the selected position in the video DAY&NIGHT...
  • Page 17 - Off : Motion detection mode is cancelled. SPECIAL PAGE 1 - On : Any motion in the selected areas is observed. CAMERA ID DAY&NIGHT SYNC MOTION DETECTION ZOOM PT BACKLIGHT Please select the setup button while in ON mode. AE PREFERENCE LIGHTS SAVE &...
  • Page 18 7. AE PREFERENCE The camera user has a choice to optimize the scene when high dynamic range lighting is detected by setting the Automatic Exposure Preference. SHADOW SPECIAL PAGE 1 When AE Preference is set to shadow, the camera will CAMERA ID DAY&NIGHT adjust the exposure so that dark parts of the image are...
  • Page 19: Special Page 2 Menu

    8. SPECIAL PAGE 2 MENU 1. MIRROR Select “OFF” to show the image as normal. Select “ON” to reflect image horizontally. SPECIAL PAGE 2 MIRROR FREEZE SHARPNESS - 8 --▪-- 8 FLICKERNESS FLUORESCENT LIGHT FACTORY RESET SYSTEM INFORMATION FW Rev SAVE &...
  • Page 20 4. FLICKERNESS ON/OFF The slow shutter mode can be used manually to reduce flicker caused from fluorescent lights when line lock synchronization is not available. SPECIAL PAGE 2 When Flickerness set to OFF, trembleming is MIRROR reduced ( Default). FREEZE When Flickerness set to ON, trembling is SHARPNESS - 8 --▪-- 8...
  • Page 21: Specifications

    9. SPECIFICATIONS MODEL DWC-540DV Image Sensor 1/3” DPS ORCA Effective Pixels 720(h) x 540 (v) Horizontal Resolution Max 540 TV Lines Scanning Frequency 15.734KHz(H), 59.944(V) Video Io Select NTSC / PAL Min. Illumination Color : 0.4 Lux ( F:1.2), ( Sense-up 32x : 0.08Lux) ) Day &...
