- Page 1 High Resolution / Day&Night COLOR DOME TYPE CAMERA MANUAL 680 TVL, 960H...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance...
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
- Page 4 ■ Precautions Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting change or flicker can It is one of the most important parts of cause the camera to work improperly.
-
Page 5: Table Of Contents
■ Contents --------------------------------- 6 1.Features --------------------------------- 7 2. Cable Connection & OSD Control --------------------------------- 8 3. Setup Menu Operation --------------------------------- 18 4. Troubleshooting --------------------------------- 19 5. Dimensions --------------------------------- 20 6. Specifications... -
Page 6: Features
1. Features ☺Ultra High Resolution 680 TV Lines Clear image quality has been achieved by employing a double-speed SONY CCD with 960H, which provides a horizontal resolution of 680 TV lines. ☺Excellent Sensitivity The built-in high sensitivity COLOR CCD enable a clear image even in 0.1Lux (color), 0.00001Lux (Sens-Up) or lower illumination. - Page 7 from being too bright, which helps you identity the object in near distance. ☺Visibility: 30m In B/W mode , the IR indicator turns on with the effective visibility of 30m at 0 Lux...
- Page 8 2. Cable Connection Cable Connection...
-
Page 9: Setup Menu Operation
3. Setup Menu Operation • Menu Structure LENS DC / VIDEO / MANUAL EXPOSURE SHUTTER AUTO / FLK / MANUAL / 1/60 LOW / MIDDLE / HIGH / OFF SENSE-UP AUTO / OFF RETURN BACK LIGHT OFF / DWDR / BLC / HSBLC WHITE BAL ATW / AWB / AWC-SET / MANUAL DAY &... - Page 10 MAIN MENU 1. LENS DC↙ Select any function you Modes can be changed ↙ 2. EXPOSURE 3. BACK LIGHT wish to operate by using using LEFT 4. WHITE BAL 5. DAY NIGHT AUTO DOWN RIGHT buttons. 6. SMART 3DNR buttons. 7.
- Page 11 SHUTTER: Select shutter speed. EXPOSURE The default value is AUTO. ▶SHUTTER AUTO ▶ AUTO, FLK, MANUAL, 1/50 HIGH SENSE-UP ON↙ AGC (Auto Gain Control) RETURN RET↙ ▶ LOW / MIDDLE / HIGH SENS-UP (Digital slow shutter) ▶ AUTO (x2~x256) 3. BACK LIGHT This function is used to view a picture more clearly under back light condition.
- Page 12 ▶ AWC->SET: To find the optimal setting for the current luminance environment in this mode, put the camera towards a sheet of white paper. ▶ MANUAL: Select this to fine-tune White MANUAL WD Balance manually. Set White Balance first by ▶1.
- Page 13 WHITE BALANCE is deactivated.) If DAY NIGHT mode is AUTO, the AGC is fixed HIGH. IR LED: if you use IR LED, select On mode. IR SMART: When the IR camera is used, this function can suppresses saturation of the picture that happens in the short distance from object and you can set area up that you want.
- Page 14 F-DNR OFF F-DNR ON 8. FUNCTION FUNCTION 1. MOTION Select any function you Modes can be changed 2. PRIVACY wish to operate by using ↙ using LEFT 3. D-EFFECT ↙ 4. IMAGE ADJ DOWN RIGHT buttons. 5. CAMERA TITLE buttons. 6.
- Page 15 2) PRIVACY (POLYGON) You may conceal specific area on the screen with this ‘PRIVACY’ function. AREA: Select the programmed privacy area (Area PRIVACY 1~8) 1. AREA 2. AREA DISPLAY ON↙ AREA DISPLAY: Turn on and off the programmed 3. COLOR IIIIIIIIIII 0~15 privacy masking.
- Page 16 - COLOR GAIN: Adjust COLOR GAIN ▶ LCD: Select this menu when using a LCD monitor - GAMMA: Adjust GAMMA level - PED LEVEL: Adjust PED level. - COLOR GAIN: Adjust COLOR GAIN LENS SHADING: When setting the zoom to maximum and Lens angle of view are saturated on screen, set ON to make the Lens edge invisible.
- Page 17 • INT : Internal Synchronization Type • L/L : Power Synchronization Type, Line-lock Press the SET button and you can select a desired phase between 0 and 359. synchronization. • When the power is DC 12V, the menu is fixed to the ‘INT’ mode. 7) LANGUAGE It can be switched to English, Korean, Polish, Turkish, Hebrew, Arab, Russian, French, Spanish, Italian, Portuguese, German, chinese, Japanese on OSD menu.
-
Page 18: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •... -
Page 19: Dimensions
5. Dimensions DOME CAMERA... - Page 20 VANDAL DOME CAMERA IR VANDAL DOME CAMERA...
-
Page 21: Specifications
6. Specifications ▪ GENERAL Signal system NTSC 1/3” 960H Super HAD Sony CCD∥ Image Sensor Total Pixels 1028(H)X508(V) 1028(H)X596(V) Effective Pixels 976(H)X494(V) 976(H)X582(V) Resolution 680 TV lines (B/W 750 TV Lines with ICR) Scanning Frequency 15.734KHz(H), 60Hz(V) 15.625KHz(H), 50Hz(V) Min. Illumination 0.00001Lux(50IRE) with DSS(256x) Day &... - Page 22 Dome type Number Install Type Indoor Indoor Indoor 100x76.5(H) 120x95(H) 100x103(H) Dimension(mm) 3 Axis 2 Axis 2 Axis 3Axis Material Plastic Body & Bubble Plastic Body & Bubble PC Bubble & Plastic Body Weight 300g 560g 400g Power Max 1.8W Max 2.5W Max 2.5W Consumption...
- Page 24 DISTRIBUTED BY...
