- Page 1 COLOR DOME TYPE CAMERA MANUAL 680TVL /WDR...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 3: Table Of Contents
■ Contents 1. Features --------------------------------- 2. Precautions --------------------------------- 3. Cable Connection & OSD Control --------------------------------- 4. Camera Operation --------------------------------- 5. Troubleshooting --------------------------------- 6. Dimensions & OSD Board --------------------------------- 7. Specifications ---------------------------------... -
Page 4: Features
1. Features ■ 1/3" 520K/610K Sony Double Scan CCD II Minimum Resolution 0.1 Lux (F1.2, 50 IRE), S/N Ratio 52dB ■ High Resolution 680 TV Lines This camera has realized high resolution of 680 TV lines using the top-notch full digital image processing, 12 Bit A/D serial signal processing and special algorithm technologies. -
Page 5: Precautions
2. Precautions Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting change or flicker can It is one of the most important parts of cause the camera to work improperly. -
Page 6: Cable Connection & Osd Control
3. Cable Connection and OSD Control 1) Cable Connection 2) OSD Control SETUP button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. UP & DOWN buttons : Used for selecting items by moving the cursor up or down on the menu screen. -
Page 7: Camera Operation
4. Setup Menu Operation 4. Camera Operation Please press the SETUP button, Settings can now be made. The SETUP menu is displayed on the monitor. Please select any function you wish to activate by using the UP and DOWN buttons. The arrow can be moved up or down by using the UP and DOWN buttons. -
Page 8: Pict Adjust
■ PICT ADJUST PICT ADJUST The function is used to set the image adjustment MIRROR terms. CONTRAST MIRROR SHARPNESS (OFF/V-FLIP/H-FLIP/HV-FLIP) Set the horizontal flip for display output. GAIN CONTRAST (000 – 255) RETURN Set the screen contrast. SHARPNESS (000 – 255) Set the screen sharpness. - Page 9 ▶USER1 USER1 Outdoor fixed gain B-GAIN B-GAIN: Used for operating the Blue gain in the R-GAIN WB fixed gain mode. RETURN R-GAIN: Used for operating the Red gain in the WB fixed gain mode. USER2 ▶USER2 B-GAIN Fluorescent light fixed gain R-GAIN B-GAIN: Used for operating the Blue gain in the RETURN...
- Page 10 HLC: ON/OFF HLC/BLC CLIP LEVEL (0~255) SCALE (0~255) CLIP LEVEL BLC: ON/OFF SCALE ※ When the WDR is ON, the BLC is not working and when the BLC is ON, the HLC is RETURN not available. ■ DNR The function is used to set the Digital Noise LEVEL MIDLOW Reduction.
- Page 11 SMART IR AREA SMART IR AREA TOP (1~136), BOTTOM (1~144) BOTTOM LEFT (1~223), RIGHT (1~239) LEFT RIGHT RETURN ▶COLOR: Color only ▶B/W: Only b/w BURST (OFF): Burst signal OFF BURST BURST (ON): Burst signal ON SMART IR SMART IR (OFF): SMART IR OFF SMART IR (ON): SMART IR ON RETURN ▶EXT1: External Input1...
- Page 12 ■ DZOOM / DIS The function is used to set the digital zoom factor and position. Digital Image Stabilization will set the anti-shake compensation. DZOOM/DIS ▶DZOOM(DIGITAL ZOOM) RATIO RATIO (000 – 255): Enlarge the screen with DIGITAL ZOOM. TILT PAN (000 – 255): Move the screen left and right in D-ZOOM setting RETURN TILT (000 –...
- Page 13 ■ MOTION ON MOTION The function is used to set the motion detection DETECT SENSE operation. BLACK DISP DETECT SENSE (000 – 127): Set the motion DETECT detection sensitivity MONITOR AREA BLOCK DISP: Control the ON/OFF status of the motion detection block display RETURN DETECT AREA: Set the motion detection area MONITOR AREA: Set the Monitoring frame...
- Page 14 ■ CAMERA SET CAMERA SET The function is used to set the camera Title and TITLE communication. SYNC TITLE (OFF/ON) VERSION Camera TITLE display ON/OFF RETURN SYNC INT The current synchronization mode VERSION Camera VERSION displays. ■ LANGUAGE (Multi Language) The function is used to select the language in which to display the internal OSD menu.
-
Page 15: Troubleshooting
If there are problems in operation, please refer to the items below. If the problem persists, Troubleshooting please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •... -
Page 16: Dimensions & Osd Board
6. Dimensions & OSD Board Configurations DOME CAMERA... - Page 17 VANDAL DOME CAMERA...
- Page 18 IR VANDAL DOME CAMERA...
-
Page 19: Specifications
7. Specifications ▪ GENERAL MODEL WDR CAMERA Signal system NTSC 1/3” 960H double Scan Sony CCD∥ Image Sensor Total Pixels 1028(H)X508(V) 1028(H)X596(V) Effective Pixels 976(H)X494(V) 976(H)X582(V) Resolution Max. 680 TV lines (B/W 750 TV Lines with ICR) Scanning Frequency 15.734KHz(H), 60Hz(V) 15.625KHz(H), 50Hz(V) Shutter Speed 1/60~1/10,000 sec... - Page 20 Dome type Number Install Type Indoor Indoor Indoor Indoor 100x76.5(H) 120x95(H) 100x103(H) 81x87(H) Dimension(mm) 3 Axis 2 Axis 2 Axis 3Axis 3Axis Material Plastic Body & Plastic Body & PC Bubble & PC Bubble & Bubble Bubble Plastic Body Plastic Body Weight 300g 560g...
