Interfaces - powersoft M30D HDSP+ETH User Manual

1 2 3
6 7
8 9
1. Channel 1 input attenuator
2. Channel 1 meter LEDs
3. Channel 2 meter LEDs
4. Channel 2 input attenuator
5. On/off power switch
6. Channels 1&2 ready LED
7. Channels 1&2 temperature warning LED
4
FIGURE 2: M Series – MxxD front panel view.
FIGURE 3: M Series – MxxD (non HDSP+ETH) rear panel view.
15 16 17 18 19
HDSP+ETH rear panel view.
8. AC mains power plug
9. Air vents
10. Channels 1&2 line output XLR connector
11. Channels 1&2 line input XLR connector
12. Channel 2 output Speakon connector
13. Link switch channels 1-2
14. Channel 1 output Speakon connector
10
12
FIGURE 4: M Series
15. Amplifier's remote ID selector
16. Preset LEDs
17. Preset selector button
18. AUX supply plug
19. Ethernet port
5
11
13 14
