Figure 27. Attaching the dome to the housing (cameras not shown to show safety clips clearly)
Flush-mount housing
Flush-mount housing and bubble ring
and dome ring
Safety clip
Safety clip
Safety cable
Safety cable
Cast aluminum (rugged) pendant-mount housing
Cast aluminum (rugged) pendant-mount
and bubble ring
housing and dome ring
Tamper-resistant
Tamper-resistant
threaded captive
threaded captive
bubble screws (6)
dome screws (6)
Note: Use the provided
Torx-pinned bit.
Plastic pendant-mount housing and bubble ring
Cameras not shown
in diagrams
so that safety clips
are clearly visible.
Self-locking, quarter-turn
Self-locking, quarter-turn
captive dome screws (3)
captive bubble screws (3)
Self-locking, quarter-turn
Self-locking, quarter-turn
captive dome screws (3)
captive bubble screws (3)
CAUTION: Do not use a power drill
with the self-locking, quarter turn
captive screws.
around the bubble ring)
around the dome ring)
Safety clip
Safety clip
dome slots (2)
Bubble slots (2)
Safety cable
Safety cable
dome tabs (2)
Bubble tabs (2)
Camera assembly, shroud, dome
Plastic pendant-mount housing and
dome ring
O-ring
O-ring
(ensure it is in place
(ensure it is in place
Heavy duty housing and bubble ring
Heavy duty housing
and dome ring
Safety clip
Safety clip
Chapter 4
Safety clip
Safety clip
Safety cable
Safety cable
Safety sable
Safety cable
Keylock latch
Keylock latch
33
