GE Security CyberDome II Installation Manual page 23

Figure 13. Installing the flush-mount housing
Safety cable
3/4 in. conduit knockouts (2)
Nipple
(snipped off to access
the safety cable clip,
which is inside the housing)
Cables fed
through mount
and housing
Clip for safety cable
(inside housing)
Flush-mount cabling
Building superstructure
Housing tabs (3)
(screwed open and down
against the mount or ceiling)
Ceiling ring
Angle brackets (2)
Ceiling
Cables are fed through: the cable entry hole in the
side (or top) of the housing. Route the wires through
the top or side of the housing and around the
camera bracket.
Chapter 2
Housings and cables
Upper bracket
15
