- Page 1 Legend IP Installation Manual...
- Page 2 Copyright Copyright © 2006, GE Security Inc. All rights reserved. This document may not be copied or otherwise reproduced, in whole or in part, except as specifically permitted under US and international copyright law, without the prior written consent from GE.
-
Page 3: Table Of Contents
Contents Contents................iii Preface . - Page 4 Wiring Tyco/AD keypads to Legend IP domes ........
- Page 5 Index ................73...
- Page 6 Legend IP Installation Manual...
-
Page 7: Preface
Preface This is the GE Legend IP Installation Manual. It provides an overview of the product and detailed instructions explaining how to install all models. There is also information describing how to contact technical support if you have questions or concerns. For programming and operation instructions, refer to the Legend IP User Manual. -
Page 8: References
GE Security. SymSecure System Guide (1055580) • GE Security. SymSecure User Guide (online help) • GE Security. KTD-405 Controller Keypad User Manual (1036547) • GE Security. Networking Cable Types Technical Reference Guide (1047213) • GE Security. ASCII Protocol Reference Manual (1038010) -
Page 9: Introduction
Chapter 1 Introduction This chapter provides an overview of your Legend IP dome system, including product description, dome and system requirements, and system planning. In this chapter: Product description......... . 2 Installation overview. -
Page 10: Product Description
Installation Manual Product description Legend IP™ is a line of advanced PTZ domes that stream digital video. Digital video is easier to transmit, share, and store than conventional analog video signals. Digital video systems also integrate well into most communications and media networks and are easily operated from software applications that manage digital video, such as GE’s SymSecure™... -
Page 11: Operational Overview
Legend IP domes, refer to that software’s documentation for its instructions. System configurations Legend IP domes can be used in a variety of digital and analog system configurations. They still maintain their built-in receivers that decode analog commands originating from a compatible controlling devices, such as a... - Page 12 Legend IP Installation Manual Typical digital system A typical digital system is shown in Figure 1. In this configuration, control commands come from a software application, such as GE’s SymSecure or SymNav, instead of keypads or ASCII control software. The dome’s built-in encoders stream video to external decoders before it is transmitted to monitors, digital recorders, and alarm equipment.
- Page 13 Chapter 1 Introduction Typical advanced analog system A typical advanced analog system is shown in Figure 2. In this configuration, control commands pass through digital recorders and alarm equipment and video is switched to various monitors. For additional details, refer to the data sheet, user manual, or application guide.
-
Page 14: Product Contents
RS422 IN RS422 OUT SPEAKER SHIELD SPEAKER Product contents Each Legend IP dome system consists of the following: • 1 housing • 1 package containing 4 connectors (one 2-pin for power, one 4-pin for data, one blue 12-pin for six alarms, and one green 12-pin for two alarms, two relays, and UTP video), and 1 small screw driver •... -
Page 15: Components Supplied By The Customer
Introduction Components supplied by the customer Legend IP domes are part of an overall IP video system. Customers supply the other components of the system, such as network switches, IP decoders, and power management equipment. See the following recommended and required system components that the customer must supply. See... -
Page 16: Compatible Ip Decoders
• Windows XP Pro ® Compatible digital video storage devices The following digital video storage devices have been tested and found compatible with Legend IP domes. For performance differences, see Storage requirements and options on page 16. • GE’s SymSecure NVR archiver •... -
Page 17: Dome Requirements
Chapter 1 Introduction Dome requirements For proper operation, adhere to the following operational, load, cable, and power requirements for Legend IP domes. Minimum load requirements Table 1 lists the load requirements for all Legend IP dome configurations. CAUTION: For safety, the mounting surface, hardware, and procedure used for securing the dome must support the weight of the dome, mount (if used), cables, and any structural or environmental vibration according to local codes. -
Page 18: Cable Management
Legend IP Installation Manual Cable management Follow all local codes for cable management. As a general rule, you can fill a cable conduit to a maximum of 60% of its capacity. You must maintain 40% free space. A variety of factors will determine how many cables you can run into the dome. -
Page 19: Power Requirements
Introduction Power requirements All Legend IP domes require a 24 VAC power supply to operate the domes’ PTZ, camera, and heater/blower, if present. The startup and running power requirements vary depending on the model (Table 3). Be aware that Legend IP domes have greater power requirements than do CyberDome or analog Legend domes, which may require upgrading the power cabling for Legend IP domes. -
Page 20: System Planning
Consider each of the following related issues. If you have questions that this section does not answer, GE Security has system design engineers available to help you design your system. Contact your dealer, sales representative, or GE Security at www.gesecurity.com. - Page 21 Chapter 1 Introduction Needed network switch features Network switches have many associated features, but only a few affect the transmission of digital video and need to be considered when designing a system. Those few are port speed, switching capacity, multicast protocol, and IGMP snooping.
- Page 22 Legend IP Installation Manual can expect many switches to turn on this feature by using a serial cable to configure the IP address of the built- in management interface, then accessing that interface and using a web browser to change the settings.
-
Page 23: Video Resolution And Compression Standards
Video resolution and compression standards affect video quality, file size, and storage requirements. Table 7 and Table 8 outline the video and compression standards that are available with Legend IP and SymSuite products. Program your system with the standards that will best meet your overall surveillance needs. -
Page 24: Storage Requirements And Options
If you are using a SymSecure NVR archiver to archive your recorded video, refer to the Storage size section of the SymSecure System Guide (1055580). If you are using other video storage equipment, contact GE Security System Design or Technical Support for assistance in estimating storage requirements and choosing... -
Page 25: Networking Ip Domes
It can also synchronize the time for networked domes. Alarm management There are eight built-in alarm inputs in the housings of the Legend IP domes to use as internal alarm triggers. Changes of alarm status are sent through the network interface to specified IP addresses... - Page 26 Legend IP Installation Manual Security options You can actively protect access to your Legend IP domes three ways—with passcodes, SSL, and IP filtering. Passcodes The passcodes (Using passcodes on page 47) control who has access to the features of your dome. Only the installer through the installer passcode has permission to turn on, turn off, or change the passcodes.
-
Page 27: Viewing Options
Chapter 1 Introduction Viewing options GE offers four products for viewing digital video—two are free. You can use (Figure 5): • the free SymNav software on a computer (provided); • the free SymBrowser plug-in on a computer (not provided); • a SymNet device attached to a keypad and monitor;... - Page 28 Legend IP Installation Manual...
-
Page 29: Chapter 2. Installing The Housing And Cables
Chapter 2 Installing the housing and cables This chapter provides instructions for installing the housing and cables. In this chapter: Various mounting and housing styles ......22 Flush-mount housings. -
Page 30: Various Mounting And Housing Styles
Legend IP Installation Manual Various mounting and housing styles There are three basic mounting styles: pendant, wall, and flush. A pendant-mount lowers a dome from a ceiling, a wall-mount extends a dome from a wall, and a flush-mount raises a dome’s bubble even with a ceiling. -
Page 31: Flush-Mount Housings
Chapter 2 Installing the housing and cables Flush-mount housings Flush-mount and pendant-mount housings require different preparation of the mounting surface and different installation procedures of the housings. Follow the instructions given here for flush-mount housings. CAUTION: The flush-mount housing is for indoor applications only. Do not expose it to moisture, or the unit may be damaged. -
Page 32: Installing The Housing
Legend IP Installation Manual Installing the housing With the surface prepared and/or the mount now installed, install the housing. To install the housing, see Figure 9 on page 25 and do the following: 1. Remove either conduit knockout (side or top) in the housing. - Page 33 Chapter 2 Installing the housing and cables Figure 9. Installing the flush-mount housing Building superstructure Safety cable Housing tabs (3) (screwed open and down against the mount or ceiling) 3/4 in. conduit knockouts (2) Ceiling ring Angle brackets (2) Ceiling Nipple Cables fed (snipped off to access...
-
Page 34: Pendant-Mount Housings
Legend IP Installation Manual Pendant-mount housings Pendant-mount and flush-mount housings require different preparation of the mounting surface and different installation procedures of the housings. Follow the instructions given here for pendant-mount housings. Pendant-mount housings can be mounted to a pipe to lower them from a ceiling or to a wall-mount arm to extend them from a wall. -
Page 35: Installing The Housing
Chapter 2 Installing the housing and cables Installing the housing With the pipe or mount now installed, install the housing. If you are installing the housing outdoors and onto a pipe, you must install the rubber water-sealing boot that provides an additional layer of water protection. Applying PTFE thread sealing tape (for example, Teflon ®... - Page 36 Legend IP Installation Manual Figure 10. Installing the pendant-mount housing Typical pipe-mount Ceiling Ceiling Water-sealing rubber boot Water-sealing rubber boot (for outdoor applications) (for outdoor applications) Soapy water Teflon tape sprayed on Teflon tape applied to pipe before pipe threads after the the boot is boot is slid up.
-
Page 37: Preparing The Cables
Chapter 2 Installing the housing and cables Preparing the cables Which and how many cables you will be preparing depends upon how many alarms and relays you are connecting in addition to the Ethernet and power cables, and whether you will be installing cables for analog video and data. - Page 38 Legend IP Installation Manual...
-
Page 39: Chapter 3. Wiring And Addressing The Dome
Chapter 3 Wiring and addressing the dome This chapter provides instructions for how to wire and address the dome. There are two boards attached up inside of the housing that you will be handling while you wire and address the dome. The larger board is the housing board and the smaller board is the active housing card (AHC). -
Page 40: Components Used For Basic And Advanced Operation
Legend IP Installation Manual Components used for basic and advanced operation For basic operation, you need to connect Ethernet and power cables to the components in the dome shown in Figure 12. The Ethernet connection provides both video and data. For advanced operation, you can also connect any combination of alarm, relay, or analog data and video cables to the dome. -
Page 41: Wiring The Housing Board
Use the provided 2-pin terminal strip. If you are using a heavier gauge cable, ensure that it is properly seated in the connector. Power in the Legend IP domes is not polarity sensitive. -
Page 42: Ethernet And Power Connections
Legend IP Installation Manual Figure 13. Connecting the digital video and data Ethernet, power, alarm/relay, and analog data and video cables Ethernet and power connections Alarm/relay connections Note: Use dry contacts for alarms and use relays with a maximum HEATER/BLOWER... - Page 43 Chapter 3 Wiring and addressing the dome Figure 14. Completed wiring in housings Front of housing Front of housing PTZ clearance notch PTZ clearance notch (indicates front of housing) (indicates front of housing) Note: Route cables away from heaters, if heaters are Upper bracket Upper bracket present.
-
Page 44: Installing The Cable Ring
Legend IP Installation Manual Installing the cable ring The cable ring moves the cables away from the center of the housing so that the camera assembly installs easily and no wires are pulled loose. To install the cable ring, see Figure 15 and do the following: 1. -
Page 45: Addressing The Camera Site And Setting The Protocol
Chapter 3 Wiring and addressing the dome Addressing the camera site and setting the protocol The dome provides rotary switches for setting the camera’s site address and communication protocol. Site addresses can be numbered from 0 to 1599. To set the camera’s site address and protocol, see Figure 16 and Table 9 on page 38 and do the following: 1. - Page 46 Legend IP Installation Manual New protocols have continued to be added since the earliest analog Legend domes. Table 9 gives the switch assignments for the currently available protocols. Be aware that some protocols have moved from what setting they are on.
-
Page 47: Setting The Termination
(RS-422) protocol. To wire a Tyco/AD (RS-422) keypad to the dome, see Upgrading Legend to Legend IP <<<waiting for card info>>> on page 71. For details about streaming position reporting, see the Legend IP User Manual (1055713). To set the termination, see Figure 17 and do the following: •... - Page 48 Legend IP Installation Manual...
-
Page 49: Chapter 4 Installing The Camera Assembly And Bubble
Chapter 4 Installing the camera assembly and bubble This chapter provides instructions for installing the camera assembly and bubble. In this chapter: Installing the camera assembly....... . 42 Installing the bubble . -
Page 50: Installing The Camera Assembly
Legend IP Installation Manual Installing the camera assembly Most people can install the camera assembly with one hand. If you need to use two hands, do so. After installation, the drive mechanism pauses for up to 30 seconds, then it performs a PTZ self-test and initializes. - Page 51 Chapter 4 Installing the camera assembly and bubble Figure 19. Installing the camera assembly Alignment tabs (2): One is orange on the inside and mates with the orange alignment slot, and one is white on the inside and mates with the white alignment slot. Upper bracket Standoff posts (3) Interconnect...
-
Page 52: Installing The Bubble
Legend IP Installation Manual Installing the bubble There are a variety of bubbles and housings. The interlocking clips and safety cables may vary, but all bubbles have them. CAUTION: To prevent damage, do not touch the bubble with your bare hands, do not place the bubble face down on any surface, and protect the bubble from dust. - Page 53 Chapter 4 Installing the camera assembly and bubble Figure 20. Attaching the bubble to the housing (cameras not shown to show safety clips clearly) Flush-mount housing Plastic pendant-mount housing Flush-mount housing and bubble ring Plastic pendant-mount housing and bubble ring and bubble ring and bubble ring Cameras not shown...
- Page 54 Legend IP Installation Manual...
-
Page 55: Chapter 5 Using Passcodes
Chapter 5 Using passcodes This chapter provides instructions for turning on the passcodes for the dome. Using passcodes is optional. They are off by default. In this chapter: Passcodes off by default ........48 Turning on passcodes . -
Page 56: Passcodes Off By Default
Passcodes off by default Legend IP domes ship with the passcodes turned off. When you enter the programming interface for the first time during installation and go to the Passcode page under the Setup menu, the passcode fields are blank. - Page 57 (Figure 26). Note: For complete instructions for navigating the programming interface and programming with it, refer to the Legend IP User Manual (1055713). Figure 26. First screen of programming interface when passcodes are turned off...
- Page 58 Legend IP Installation Manual 7. Turn on the desired passcodes (Figure 27): a. Select Setup and Passcode. b. Select the ab (keyboard) icon next to the Installer passcode. c. Select the digits for a unique passcode. There is an 4-digit limit.
-
Page 59: Chapter 6. Troubleshooting, Maintenance, Support
Chapter 6 Troubleshooting, maintenance, support This chapter provides information to help you troubleshoot problems, perform simple preventive maintenance procedures, and contact technical support in case you need assistance with your GE equipment. In this chapter: Troubleshooting ......... . . 52 Common installation issues . -
Page 60: Troubleshooting
Following are the most common troubleshooting issues and their solutions. Note: For programming and operating issues, refer to the Legend IP User Manual (1055713) and the user manual for your controller keypad. • The dome is resetting during power-up, not powering up at all, or powering up but not operating as expected. -
Page 61: Diagnostic Leds
Chapter 6 Troubleshooting, maintenance, support Diagnostic LEDs There are diagnostic LEDs that are visible underneath the dome. The housing board LED is visible before you install the camera assembly. The camera assembly LEDs are visible after you install the camera assembly. Housing board power indication When power is received by the housing board through the power connection, the housing board’s diagnostic power LED will appear orange. -
Page 62: Verifying Network Connections
In ping -l 1500 yourIPaddress, the -l is a hyphen and lowercase L and the 1500 is the standard packet size used by GE Security products. If the dome’s or computer’s Internet connections are correct, all packets contained in the message will show as having been sent and received (Figure 31 on page 55). - Page 63 Chapter 6 Troubleshooting, maintenance, support Figure 31. Pinging a dome or computer 4. Properly exit the DOS window by typing exit at the C:\> prompt and pressing Enter.
-
Page 64: Maintenance
To reset the dome, cycle the power to the dome by turning the power off then on. Rebooting the dome You can only reboot Legend IP domes from GE KTD-405 keypads. To reboot a dome, do the following from the KTD-405 keypad: 1. -
Page 65: Cleaning The Bubble
Chapter 6 Troubleshooting, maintenance, support Cleaning the bubble Use the following procedures for cleaning the bubble. Be aware that the interior of the bubble requires extra care in cleaning. Use only the procedures provided below. For warranty protection, comply with this section’s bubble handling procedures. CAUTION: To prevent damage, do not touch the bubble with your bare hands, do not place the bubble face down on any surface, and protect the bubble from dust. -
Page 66: Spare Parts List
Legend IP Installation Manual Spare parts list Table 10 provides a listing of all parts that can be replaced or retrofitted for the dome. Table 10. Purchasable spare parts Part name Item number Bracket, upper 1048840 Bubble, flush-mount, clear acrylic... -
Page 67: Contacting Technical Support
Chapter 6 Troubleshooting, maintenance, support Contacting technical support For assistance installing, operating, maintaining, and troubleshooting this product, refer to this document and any other documentation provided. If you still have questions, you may contact technical support during normal business hours (Monday through Friday, excluding holidays, between 5 a.m. and 5 p.m. Pacific Time). Table 11. - Page 68 Legend IP Installation Manual...
-
Page 69: Appendix A Installing The Individual Mounts
Appendix A Installing the individual mounts This appendix provides the installation instructions for the mounts that are shipped with the dome kits, which includes the wall-mount arm and the T-bar support kit. Instructions for all other mounts (arms, adapters, and brackets) are shipped with those mounts. -
Page 70: Gea-102 Wall-Mount Arm
Legend IP Installation Manual GEA-102 wall-mount arm The cast aluminum wall-mount arm is used to mount a dome to a vertical surface. It is for indoor or outdoor use and mates with both the plastic indoor and cast aluminum outdoor pendant housings. It can be attached directly to a vertical surface or mated with a bracket (corner-mount, pole-mount, or roof-mount). - Page 71 3. Remove the access cover (Figure 33). Figure 33. Removing the access cover 4. Using the arm as a template, place it level against the mounting surface and mark the position of the mounting holes, and if needed, the cable entry hole (Figure 34). Figure 34.
- Page 72 Legend IP Installation Manual 7. Securely fasten the arm to the mounting surface with the appropriate fasteners (Figure 35). Again, ensure that it is level. Figure 35. Fastening the arm to the mounting surface Note: Adhere to minimum load requirements. See Table 1 on page 9.
-
Page 73: Opening The Conduit Hole
11. Before you attach the housing to the arm, attach the housing safety cable to the arm safety chain (Figure 37). Note: The safety cable for rugged housings is metal and for plastic housings is a beaded cord. a. Cut the quick tie on the safety chain. b. - Page 74 Legend IP Installation Manual Figure 38. Opening a conduit hole Pilot hole 3/8 in. (10 mm) Enlarged hole For 3/4 in. conduit: 1-7/64 in. (28 mm) For 1/2 in. conduit: 7/8 in. (22 mm)
-
Page 75: Gea-114 T-Bar Ceiling Support Kit
GEA-114 T-bar ceiling support kit The T-bar support kit is used to install a flush-mount dome into a paneled T-bar ceiling (Figure 39). T-bar ceilings consist of a grid of metal T-bars that support removable panels. The kit distributes the weight of the dome between the T-bars of the ceiling, instead of resting it on a panel. -
Page 76: Installing The T-Bar Ceiling Support Kit
Legend IP Installation Manual Installing the T-bar ceiling support kit One side of the ceiling ring is flat; the other side has two press nuts. Orient the ceiling ring as directed in the instructions. CAUTION: For all installations, heed these cautions: •... - Page 77 4. Following all local codes, drill the mounting holes (use a 3/16 in. drill bit) and cut the housing pass- through hole. Drill/cut all holes perpendicular to the panel and be careful not to overcut the housing pass-through hole. 5. Reset the angle brackets and ceiling ring on the removable ceiling panel aligning the center mounting holes of the brackets and ring with the drilled holes in the panel.
- Page 78 Legend IP Installation Manual...
-
Page 79: Appendix B Tyco/Ad Wiring
....72 Wiring Tyco/AD keypads to Legend IP domes ....72... -
Page 80: Verifying Dome Software And Ahc Firmware Versions
To verify the software version of the domes and the firmware version of the installed AHCs: 1. Select System and Status in the menus of the graphical programming interface. Refer to the Legend IP User Manual (1055713) for details about using the programming interface. - Page 81 Index active housing card (AHC) ...............31, 32 graphical programming interface............48 addressing ..................37, 38 housings boards aluminum pendant-mount..............22 flush-mount................22, 23, 25 active housing card (AHC)............31, 32 heavy-duty ..................22 housing ...................31, 32, 33 mounting styles ...................22 later revisions ..................32 pendant-mount................22, 26, 28 bubbles ....................44, 45 plastic pendant-mount ................22 cleaning ....................57...
- Page 82 Legend IP Installation Manual product contents....................6 description ....................2 safety cautions programming interface................48 bubble ...................44, 57 cables..................24, 27, 33 protocols..................2, 37, 38 captive screws ................44, 45 PTFE thread sealing tape ................27 heaters ................24, 27, 33, 43 PTZ self-test....................42 installation................23, 26, 62, 68 publication library...................59...
