  • Page 1 User Manual ASMB-820I...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Our dealers are well trained and ready to give you the support you need to get the most from your Advantech products. In fact, most prob- lems reported are minor and are easily solved over the phone.

  • Page 4: Declaration Of Conformity

    Caution! There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer's instructions. ASMB-820I User Manual...
  • Page 5 4G DDR3-1333 240PIN ECC M3CN-4GHJ3C09 ADATA 4G DDR3-1333 240PIN ECC EL03I1C18 ADATA 4G DDR3-1600 240PIN EL64C1C16 Memory / 96D3-4G1333NN-TR Transcend 4G DDR3-1333 240PIN TS512MLK64V3N Cooler 1960055362N011 Cooler I-LGA1356/1366 S-95W 90x90x65.65-SS(M3) Z6UR41J002 Option PCA-AUDIO-HDA1E Advantech Audio card Card ASMB-820I User Manual...
  • Page 6 It should be free of marks and scratches and in perfect working order upon receipt. When unpacking the ASMB-820I, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is dam- aged or it fails to meet the specifications, notify our service department or local sales representative immediately.

  • Page 7: Table Of Contents

    Clear CMOS Connector (JCMOS1) ............19 2.17 PMBUS Connector (PMBUS1)..............19 2.18 Front Panel SMBUS Connector (SMBUS1) ..........20 2.19 IPMI Module Connector (IPMI1)* ............20 2.20 VOLT1 Connector ................... 21 Chapter AMI BIOS ..........23 Introduction ..................... 24 ASMB-820I User Manual...
  • Page 8 Power LED (JFP1) .................. 72 Table B.7: Power LED (JFP1) ........... 72 External Speaker Connector (JFP1) ............73 Table B.8: External Speaker Connector (JFP1) ......73 Reset Connector (JFP1) ................. 73 Table B.9: Reset Connector (JFP1)........... 73 ASMB-820I User Manual viii...
  • Page 9 8-pin Alarm Board Connector (VOLT1)........... 75 Table B.15:8-pin Alarm Board Connector (VOLT1) ....75 B.16 Case Open Connector (JFP1)..............76 Table B.16:Case Open Connector (JFP1) ........76 B.17 Front Panel LAN LED Connector (LANLED1)......... 76 Table B.17:LAN LED Connector (LANLED1)......76 ASMB-820I User Manual...
  • Page 10 ASMB-820I User Manual...

  • Page 11: Chapter 1 Overview

    Chapter Overview...

  • Page 12: Introduction

    The serverboard supports an Intel Xeon E5-2400 series processor and DDR3 1066/ 1333/1600 MHz memory up to 96 GB. ASMB-820I provides dual PCIe x16 slots (1 x8 link; 1 x16 link) which can support two high performance graphic cards. For multi-interface expansion card applications, ASMB-820I can also support 1* PCIe x1 &...

  • Page 13: Specifications

     2 x RJ-45 LAN ports (10/100/1000 Base-T LAN).  1 x RJ-45 Dedicated IPMI LAN port(10/100 Base-T) for IPMI only, there is no regular LAN function (ASMB-820I Only).  4 x USB ports at rear window.  3 x USB internal headers (6 ports).
  • Page 14  Operating Temperature: 0 to 60°C Non-operating Temperature: -40 to 85°C   Operating Relative Humidity: 0% to 90% (non-condensing)  Non-operating Relative Humidity: 5% to 95% (non-condens- ing) Note! Specifications are subject to change without notice. ASMB-820I User Manual...

  • Page 15: Board Layout, Jumpers And Connectors

    Board Layout, Jumpers and Connectors Connectors on the ASMB-820I are linked to external devices such as hard disk drives. In addition, ASMB-820I has a number of jumpers that are used to configure system for specific applications. The tables below list the functions of each jumper and connector. Later sections in this chapter give instructions for setting jumpers.

  • Page 16: Table 1.2: Onboard Lan Led Color Definition

    Serial ATA1 hard drive connector(SATA III) SATA2 Serial ATA2 hard drive connector(SATA II) SATA3 Serial ATA3 hard drive connector(SATA II) SATA4 Serial ATA4 hard drive connector(SATA II) SATA5 Serial ATA5 hard drive connector(SATA II) SATA_SGPIO_1 SGPIO connector for SATA0 ~ SATA5 ASMB-820I User Manual...

  • Page 17: Table 1.5: Onboard Led

    Off: On (Green): No input AC Power System is ON, in sleep mode, or in soft-off mode LED1 BMC heartbeat LED Blinking (Green) : (820I SKU Only) Controller is working normally Block Diagram Figure 1.3 Block Diagram ASMB-820I User Manual...

  • Page 18: System Memory

    Quantity of memory installed Socket / Color DIMMA1 (Orange) DIMMA2 (Black) DIMMB1 (Orange) DIMMB2 (Black) DIMMC1 (Orange) DIMMC2 (Black) Processor Installation The ASMB-820I is designed for single LGA1356, Intel E5-2400 series Xeon proces- sor. ASMB-820I User Manual...

  • Page 19: Chapter 2 Connections

    Chapter Connections...

  • Page 20: Introduction

    They are supported by all major network operating systems. The RJ-45 jacks on the rear plate provide convenient 1000Base-T operation. ASMB-820I is also equipped with the additional 100 Mbps Ethernet LAN (IPMI_LAN1 Port) which is shared with IPMI for system management.

  • Page 21: Vga Connector

    VGA Connector The ASMB-820I includes a VGA interface that can drive conventional CRT and LCD displays. COM1+VGA1 Serial Ports (COM1/COM2) The ASMB-820I offers 2 serial ports (One on the rear panel and one onboard). COM1+VGA1 COM2 ASMB-820I User Manual...

  • Page 22: Ps2 Keyboard And Mouse Connectors (Kbms1)

    PS/2 keyboard and mouse connections. KBMS1 CPU Fan Connector (CPU FAN0) If a fan is used, this connector supports cooling fans that draw up to 500 mA (6 W). CPUFAN0 Table 2.1: CPU FAN0 Pin Definition CPU FAN0 +12V CPU0_TACH CPU0_PWM ASMB-820I User Manual...

  • Page 23: System Fan Connector (Sys Fan0/Fan1/Fan2/Fan3)

    System Fan Connector (SYS FAN0/FAN1/FAN2/ FAN3) SYSFAN3 SYSFAN0 SYSFAN2 SYSFAN1 Table 2.2: SYS FAN0 Pin Definition Table 2.3: SYS FAN0 SYS FAN1 SYS FAN2 SYS FAN3 +12V +12V +12V +12V FAN0_TACH FAN1_TACH FAN2_TACH FAN3_TACH FAN0_PWM FAN1_PWM FAN2_PWM FAN3_PWM ASMB-820I User Manual...

  • Page 24: Front Panel Connector (Jfp1)

    System Off 2.8.2 External Speaker (JFP1 pins 10, 12, 14, 16) JFP1 pins 10, 12, 14, 16 connect to an external speaker. The ASMB-820I provides an onboard buzzer as an alternative. To enable the buzzer, set pins 14-16 closed. 10 12...

  • Page 25: Hdd Led Connector (Jfp1 Pins 5 & 7)

    Case Open (JFP1 Pins 6 & 8) A Chassis Intrusion header is located at JFP1 on the motherboard. Attach the appro- priate cable from the chassis to be informed of a chassis intrusion when the chassis is opened. SATA SGPIO (SATA_SGPIO1) SATA_SGPIO1 ASMB-820I User Manual...

  • Page 26: Front Panel Lan Indicator Connector (Lanled1)

    2.11 Serial ATA Interface (SATA0 ~ 5) ASMB-820I features two serial ATA III (SATA 0 & SATA 1) interfaces (up to 600 MB/s) and four serial ATA II (SATA 2 ~ SATA 5) interfaces (up to 300 MB/s) which ease cabling to hard drives with thin and long cables.

  • Page 27: Expansion Slots

    Note! Please use a power supply which is of SSI type; minimum output should be at least 596W. ATX 8P_P1 & ATX 24P_P1 sockets should be connected with power supply, otherwise ASMB-820I will not boot up normally. ASMB-820I User Manual...

  • Page 28: Hd Audio Interface Connector (Audio1)

    HD Audio Interface Connector (AUDIO1) AUDIO1 +5 V_AUD ACZ_SYNC ACZ_BITCLK ACZ_SDOUT ACZ_SDIN0 ACZ_SDIN1 ACZ_RST# +AC_12V 2.15 LPC Connector (LPC1) for Optional TPM Module LPC1 CLK_33M_TPM LPC_AD1 PLTRST_LPC LPC_AD0 LPC_FRAME +3.3 V LPC_AD3 LPC_AD2 SMB_SCL_LPC SERIRQ_PCH SMB_SDA_LPC +5V_AUX ASMB-820I User Manual...

  • Page 29: Clear Cmos Connector (Jcmos1)

    2.16 Clear CMOS Connector (JCMOS1) Setting jumper from pin 1_2 to pin 2_3,then back to pin 1_2 to reset CMOS data. JCMOS1 SRTC_RST_PCH RTC_RST_PCH 2.17 PMBUS Connector (PMBUS1) PMBUS1 SMB_SCL_PM SMB_SDA_PM SMB_ALT_PM +3.3V ASMB-820I User Manual...

  • Page 30: Front Panel Smbus Connector (Smbus1)

    2.18 Front Panel SMBUS Connector (SMBUS1) SMBUS1 +3.3V_AUX SMB_SCL_FRU SMB_SDA_FRU 2.19 IPMI Module Connector (IPMI1)* IPM1 Note! To enable IPMI, you must buy an IPMI module made by Advantech. ASMB-820I User Manual...

  • Page 31: Volt1 Connector

    2.20 VOLT1 Connector VOLT1 VOLT1 connects to the alarm board of Advantech chassis. These alarm boards give warnings if a power supply or fan fails, if the chassis overheats, or if the backplane malfunctions. 5VSB +3.3V -12V +12V ASMB-820I User Manual...
  • Page 32 ASMB-820I User Manual...

  • Page 33: Chapter 3 Ami Bios

    Chapter AMI BIOS...

  • Page 34: Introduction

    The Setup program uses a number of menus for making changes and turning the special features on or off. This chapter describes the basic navigation of the ASMB-820I setup screens. AMI's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 35: Bios Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from the ASMB-820I setup screen to enter the Advanced BIOS setup screen. You can select any of the items in the left frame of the screen, such as CPU configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 36 3.2.2.1 PCI Subsystem Settings  PCI ROM Priority Default setting is EFI Compatible mode. In case PCI legacy Option ROM required, you can change the mode from EFI to Legacy. ASMB-820I User Manual...
  • Page 37 "Enable or disable" ACPI auto configuration.  Enable Hibernation "Enable or disable" hibernation.  ACPI Sleep State Specifies the ACPI sleep state when the system enters suspend.  Lock Legacy Resources "Enabled" or "Disabled" lock legacy resources. ASMB-820I User Manual...
  • Page 38 3.2.2.3 Trusted Computing  TPM Support “Enable or disable” TPM support. Purchase Advantech LPC TPM module to enable TPM function. P/N: PCA-TPM-00A1E. 3.2.2.4 WHEA Support  WHEA Support “Enable or disable” Windows Hardware Error Architecture. ASMB-820I User Manual...
  • Page 39 3.2.2.5 CPU Configuration  Socket 0 CPU Information  Hyper-threading Enable or disable Intel Hyper Threading technology.  Active Processor Core Select how many processor cores to activate when using a dual or quad core processor. ASMB-820I User Manual...
  • Page 40 It allows multiple operating systems to run simultaneously on the same system. It does this by creating virtual machines, each running its own x86 operating system.  CPU Power Management Configuration Power technology default is “Energy Efficient”. ASMB-820I User Manual...
  • Page 41 User can set “EIST”, “P-STATE”, “C3”, “C6”, “C7”, “Package C State limit” under “Custom” Mode. 3.2.2.6 Runtime Error Logging User can enable or disable Runtime Error Logging Support. ASMB-820I User Manual...
  • Page 42 0 and two SATA devices are supported by controller 1 when under these operating systems. Serial-ATA Controller 1 This item appears only when SATA Mode item to [IDE Mode] is set. Set to [Enhanced] to support two SATA 3.0 Gb/s devices. ASMB-820I User Manual...
  • Page 43 Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of com- mands.  RAID Mode Set to [RAID Mode] to create a RAID configuration from the SATA hard disk drives. ASMB-820I User Manual...
  • Page 44 This item appears only when Device power-up delay item is set to [manual].  Mass Storage Devices This item appears only when plugging in a USB flash device. Users can choose “Auto”, “Floppy”, “Forced FDD”, “Hard Disk” and “CD-ROM” to simulate USB flash devices. ASMB-820I User Manual...
  • Page 45 3.2.2.9 Super I/O Configuration Serial Port 0 Configuration  Serial Port To “enable” or “disable” Serial Port 0.  Change Settings To select an optimal setting for serial port 0. ASMB-820I User Manual...
  • Page 46 Serial Port 1 Configuration  Serial Port To “enable” or “disable” Serial Port 1.  Change Settings To select an optimal setting for serial port 1. 3.2.2.10 H/W Monitor ASMB-820I User Manual...
  • Page 47  Watchdog Timer Enable and Disable the watchdog timer function.  Smart Fan Mode Configuration When set to manual mode, fan duty setting can be set; the range is from 0~255, default setting is 127. ASMB-820I User Manual...
  • Page 48 3.2.2.11 Serial Port Console Redirection  Console Redirection To “Enable or disable" console redirection feature,  Console Redirection Settings  Terminal Type Select a terminal type to be used for console redirection. Options available: VT100/VT100+/ANSI /VT-UTF8. ASMB-820I User Manual...
  • Page 49 With this mode enabled, only text will be sent. This is to capture Terminal data. Options available: Enabled/Disabled.  Legacy OS Redirection Resolution On Legacy OS, the number of Rows and Columns supported redirection. Options available: 80x24/80X25.  Putty Keypad ASMB-820I User Manual...
  • Page 50 "9600", "19200", "57600", or "115200". "115200" is the default set- ting. Flow Control Flow control can prevent data loss from buffer overflow. It can be set as "None", "Hardware RTS/CTS", or "Software Xon/Xoff". "None" is the default setting. ASMB-820I User Manual...

  • Page 51: Chipset

    3.2.3 Chipset 3.2.3.1 North Bridge Patrol Scrub Enable/Disable patrol scrub feature Demand Scrub Enable/Disable demand scrub feature ASMB-820I User Manual...
  • Page 52 PORT 2A Link Speed Select Target Link Speed Gen1, Gen2, Gen3 IOU3 - PCIe Port(PCIEX16_SLOT6) Functions visible based on this setting : x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16PORT 3A Link Speed Select Target Link Speed Gen1, Gen2, Gen3 ASMB-820I User Manual...
  • Page 53 Intel(R) VT for Directed I/O Configuration Intel VT-d Enable/Disable Intel Virtualization Technology for Directed I/O DIMM Information ASMB-820I User Manual...
  • Page 54 Enable/Disable SLP_S4 Assertion Stretch function  Onboard SATA RAID Oprom Enable/Disable onboard SATA RAID option rom if Launch Storage Oprom is enabled.  Azalia HD Audio Enable/Disable Azalia HD audio function  High Precision Timer Enable/Disable high precision timer function ASMB-820I User Manual...
  • Page 55 Enable/Disable Intel 82579LM controller wake up from S5 support.  LAN2 Controller Enable/Disable Intel 82574L Controller support  LAN2 PXE Oprom Enable/Disable Boot option for Intel 82574L controller.  LAN2 Wake up From S5 Enable/Disable Intel 82574L controller wake up from S5 support. ASMB-820I User Manual...
  • Page 56 All USB Devices Enable/Disable all USB devices  EHCI Controller 1 Enable/Disable USB 2.0 (EHCI) support  EHCI Controller 2 Enable/Disable USB 2.0 (EHCI) support  USB Port 0 ~ 11 Enable/Disable USB 0 ~ 11 port ASMB-820I User Manual...

  • Page 57: Server Management

    3.2.3.3 ME Subsystem 3.2.4 Server Management  BMC Support Enable/Disable interfaces to communicate with BMC ASMB-820I User Manual...

  • Page 58: Boot

    Disable the logging of EFI status codes or log only error code or only progress code or both 3.2.4.3 BMC Network Configuration  Configuration Address Source Select to configure LAN channel parameters statically or dynamically (by BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. 3.2.5 Boot ASMB-820I User Manual...

  • Page 59: Security

    Bootup NumLock State Select the keyboard NumLock state Quit Boot  Enable/Disable quiet boot option  Interrupt 19 Capture Enable: Allows option ROMs to trap Int 19  Boot Option Sets the system boot priorities 3.2.6 Security ASMB-820I User Manual...

  • Page 60: Save & Exit

    Restore Defaults Restore/Load default values for all the setup options  Save as User Defaults Save the changes done so far as user defaults  Restore User Defaults Restore the user default to all the setup options ASMB-820I User Manual...

  • Page 61: Chipset Software Installation Utility

    Chapter Chipset Software Installation Utility...

  • Page 62: Before Beginning

    Before Beginning To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the ASMB-820I are located on the software installation CD. Before beginning, it is important to note that most display drivers need to have the relevant software application already installed on the system prior to installing the enhanced display drivers.

  • Page 63: Windows Xp / Windows 2003 / Windows 2008 / Windows 7 Driver Setup

    Insert the driver CD into your system's CD-ROM drive. When the folder is dis- played, move the mouse cursor over the folder "01_Intel INF". Find the execut- able in the CSI folder, click to install the driver. Click the Setup icon to execute the program. ASMB-820I User Manual...
  • Page 64 ASMB-820I User Manual...

  • Page 65: Vga Setup

    Chapter VGA Setup...

  • Page 66: Introduction

    "02_Graphic chip" folder and click the executable file to complete the installation of the drivers for OS that you need. Note! Please use Windows 2008 server R2(WinS08R2) VGA driver version for Windows 7 VGA driver ASMB-820I User Manual...

  • Page 67: Lan Configuration

    Chapter LAN Configuration...

  • Page 68: Introduction

    Introduction The ASMB-820I has two Gigabit Ethernet LAN connections via dedicated PCI Express x1 lanes: GbE LAN1 - Intel 82579LM; GbE LAN2 - Intel 82574L. They offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ethernet at 1000 Mbps.
  • Page 69 ASMB-820I User Manual...
  • Page 70 ASMB-820I User Manual...

  • Page 71: Appendix A Programming The Watchdog Timer

    Appendix Programming the Watchdog Timer...

  • Page 72: Watchdog Timer Overview

    The ASMB-820I’s watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it.
  • Page 73 Unlock NCT6776F Select watchdog timer register Enable the watchdog timer function Use the watchdog timer function Lock NCT6776F ASMB-820I User Manual...

  • Page 74: Example Programs

    Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx in al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- ASMB-820I User Manual...
  • Page 75 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h Out dx, al Inc dx In al,dx Or al, 08h ASMB-820I User Manual...
  • Page 76 Dec dx ; Enable watchdog timer to be reset by mouse Mov al,0f7h Out dx,al Inc dx In al,dx Or al,80h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776F Mov al,0aah Out dx,al Enable watchdog timer to be reset by keyboard ASMB-820I User Manual...
  • Page 77 Mov dx,2eh ; unlock NCT6776F Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h ASMB-820I User Manual...
  • Page 78 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776F Mov al,0aah Out dx,al ASMB-820I User Manual...

  • Page 79: Appendix B I/O Pin Assignments

    Appendix I/O Pin Assignments...

  • Page 80: Usb Header (Usb45, Usb67, Usb89)

    USB Header (USB45, USB67, USB89) USB67 USB45 USB89 Table B.1: USB Header (USB45,USB67,USB89) Signal Signal USB_VCC5 USB_VCC5 USB_D- USB_D- USB_D+ USB_D+ VGA Connector (VGA1) Table B.2: VGA Connector (VGA1) Signal Signal GREEN BLUE H-SYNC V-SYNC ASMB-820I User Manual...

  • Page 81: Rs-232 Interface (Com2)

    RS-232 Interface (COM2) Table B.3: RS-232 Interface (COM2) Signal PS/2 Keyboard and Mouse Connector (KBMS1) Table B.4: Keyboard and Mouse Connector (KBMS1) Signal KB DATA KB VCC KB CLK M_DATA M_VCC M_CLK ASMB-820I User Manual...

  • Page 82: External Keyboard Connector (Kbms2)

    KB CLK KB DATA MS DATA MS CLK System Fan Power Connector (SYSFAN0~3) Table B.6: Fan Power Connector (SYSFAN0~3) Signal +12 V DETECT Power LED (JFP1) Table B.7: Power LED (JFP1) Function LED power (3.3 V) Ground ASMB-820I User Manual...

  • Page 83: External Speaker Connector (Jfp1)

    External Speaker Connector (JFP1) Table B.8: External Speaker Connector (JFP1) Function SPK_VCC SPK_OBS SPK_BUZ SPK_OUT Reset Connector (JFP1) Table B.9: Reset Connector (JFP1) Signal RESET B.10 HDD LED Connector (JFP1) Table B.10: HDD LED Connector (JFP1) Signal HDD_LED+ HDD_LED- ASMB-820I User Manual...

  • Page 84: B.11 Atx Soft Power Switch (Jfp1)

    ATX Soft Power Switch (JFP1) Table B.11: ATX Soft Power Switch (JFP1) Signal PWR-BTN B.12 Front panel SMBus Connector (SMBUS1) +3.3V_AUX SMB_SCL_FRU SMB_SDA_FRU B.13 USB/LAN Ports (LAN1_USB01 and LAN2_USB23) LAN1_USB01 LAN2_USB23 Table B.12: USB Port Signal Signal VCC_DUAL Data0+ Data0- ASMB-820I User Manual...

  • Page 85: Table B.13:Giga Lan 10/100/1000 Base-T Rj-45 Port

    Audio Connector (AUDIO1) Table B.14: Front Panel Audio Connector (FPAUD1) Signal Signal ACZ_VCC ACZ_SYNC ACZ_BITCLK ACZ_SDOUT ACZ_SDIN0 ACZ_SDIN1 ACZ_RST ACZ_12V B.15 8-pin Alarm Board Connector (VOLT1) Table B.15: 8-pin Alarm Board Connector (VOLT1) Signal Signal 5VSB +3.3V -12V +12V ASMB-820I User Manual...

  • Page 86: B.16 Case Open Connector (Jfp1)

    B.16 Case Open Connector (JFP1) Table B.16: Case Open Connector (JFP1) Signal CASEOP B.17 Front Panel LAN LED Connector (LANLED1) Table B.17: LAN LED Connector (LANLED1) Signal Signal LAN1/3_LED0_ACT LAN2/4_LED1_ACT VCC3_LAN1LED VCC3_LAN2LED LAN1/3_LED1_1000M LAN2/4_LED2_1000 LAN1/3_LED2_100M LAN2/4_LED0_100 VCC3 ASMB-820I User Manual...
  • Page 87 ASMB-820I User Manual...
  • Page 88 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2012...
