Figure 3: Connecting a VM-2HDMI 1:2 HDMI Distributor

5.2 Using the VM-2HDMI EDID SETUP Button

Initially, the VM-2HDMI operates with the factory default EDID
you connect the power before connecting either of the acceptors or the source.
You can acquire the EDID From:
The Default EDID (both output LEDs blink)
One Output (the relevant output illuminates)
You can also acquire the Clone EDID which copies the EDID data from the
acceptor bit-by-bit.
1 The VM-2HDMI reads the EDID, which is stored in the non-volatile memory
Using the VM-2HDMI 1:2 HDMI Distributor
1
. This lets
7
