5.2.1

Acquiring / Changing the EDID

You can work with the default EDID or acquire or change an EDID via one
of the connected outputs. Use the EDID Setup button to acquire the output
EDID information.
To acquire or change the EDID of a new output display:
1. Connect the power supply.
The ON LED lights.
2. Connect the new output display device.
3. Press and hold the EDID SETUP button for more than three seconds and
release.
The INPUT LED blinks and the OUT2 LED and OUT1 LED blink alternately.
4. Press the EDID SETUP button again when the appropriate OUT LED
lights, that is to copy the EDID from the display connected to the HDMI:
OUT1 connector, press the EDID button when the OUT1 LED is on
OUT2 connector, press the EDID button when the OUT2 LED is on
In either case, the VM-2HDMI copies the EDID from the display. If no
display is connected to the selected HDMI output, the default EDID will
be chosen.
Note that during the EDID setup, the respective OUT LED blinks. When that
5.2.2

Acquiring the Clone EDID

To acquire the Clone EDID, do the following
1. Connect the new output display device (for example, to OUT 1).
2. Disconnect the power supply.
3. Reconnect the power supply while pressing the EDID SETUP button.
The ON LED lights and the OUT 1 and OUT 2 blink alternately.
4. Release the EDID SETUP button when the OUT 1 LED blinks.
The Clone EDID is stored in the non-volatile memory when the OUT 1
LED ceases to blink.
1 This example refers to OUT 1. The same applies for OUT 2 if the acceptor is connected to OUT 2
8
Using the VM-2HDMI 1:2 HDMI Distributor
output is connected, that OUT LED illuminates
