Specifications - Icom IC-A24E Instruction Manual

D General
• Frequency coverage (MHz): TX
*: IC-A24E only, IC-A6E; 118.000 to 136.975 MHz
• Mode
• Channel spacing
• Number of memory channels : 200 (20 CH × 10 BANK)
• Power supply requirement : Specified battery packs/case
• Usable temp. range
• Current drain
Tx
Rx
• Antenna connector
• Dimensions
mm
(projections not incl.)
• Weight
(Without the battery pack and antenna.)
All stated specifications are subject to change without
notice or obligation.
118.000 to 136.975
RX 108.000 to 136.975*
: A3E
: 25 kHz
or 11.0 V DC at external DC
jack
: –20˚C to +55˚C
:
1.5 A typical
70 mA typical (at stand by)
300 mA typical (at AF max.)
: BNC 50 W (nominal)
: 54(H) × 129.3(W) × 35.5(D)
: Approx. 180 g

SPECIFICATIONS

D Transmitter
• Output power
• Modulation
• Modulation depth
• Audio harmonic distortion : Less than 10% (at 85% ±3 dB mod.)
• Harmonics spurious emissions
• Microphone connector
• Frequency stability
D Receiver
• Receive system
• Intermediate frequencies : 1st
• Sensitivity VOR (AM 6dB S/N): –3 dBµ typical
COM (AM 12dB SINAD): –3 dBµ typical (with CCITT)
• Squelch sensitivity
• Selectivity
• Spurious response
rejection
• Audio output power
• Hum and noise
• External SP connector
10
: 3.6 W (PEP) typical
1.0 W (CW) typical
: Low level modulation
: 85%
: Less than –36 dBm (except
operating frequency ±1 MHz
range)
: 3-conductor 2.5(d) mm ( 1 /
10
more than 100 kW
: ±5 ppm
: Double conversion
superheterodyne
30.05 MHz
2nd 450 kHz
: Less than 0 dBµ (Threshold)
: 6 dB (More than 7.5 kHz)
60 dB (Less than 25 kHz)
: More than 70 dB
: 500 mW typical
(at 10% distortion with an 8 W
load, 30% mod.)
: More than 40 dB at 90% mod.
: 3-conductor 3.5 (d) mm
˝)/8 W
( 1 /
8
˝)/
8
9
10
31
